Manufacturer Part Number
MAX3094EEUE+
Manufacturer
Analog Devices
Introduction
The MAX3094EEUE+ is a low-power, high-speed quad receiver for RS422 and RS485 communication protocols.
Product Features and Performance
Supports RS422, RS485 protocols
Features four independent receiver channels
High data rates up to 10Mbps
Low receiver hysteresis of 45 mV enhances device sensitivity
Product Advantages
Ideal for interfacing in noisy environments due to low hysteresis
Supports multiple receivers for diverse and complex applications
Low power consumption suitable for power-sensitive applications
Key Technical Parameters
Data Rate: 10Mbps
Number of Receivers: 4
Receiver Hysteresis: 45 mV
Voltage Supply: 3V to 3.6V
Operating Temperature: -40°C to 85°C
Quality and Safety Features
Rugged design tolerates extended operating temperatures
Compatibility
Compatible with RS422 and RS485 communications protocols
Application Areas
Industrial automation systems
Telecommunications infrastructure
Data network systems
Product Lifecycle
Status: Active
Not currently flagged for discontinuation; replacements or upgrades not specified
Several Key Reasons to Choose This Product
High-speed data transmission capability
Quadruple receiver channels increase system throughput
Low voltage operation helps to reduce overall power consumption
Wide operating temperature range makes it suitable for industrial applications
Compatible with popular industrial communication standards providing versatility in usage
