Manufacturer Part Number
LMC6772AIMMX
Manufacturer
Texas Instruments
Introduction
The LMC6772AIMMX is a dual general purpose comparator designed for various applications that require low power consumption and high precision.
Product Features and Performance
Dual comparator configuration
Low input offset voltage: 5mV @ 5V
Ultra-low input bias current: 0.04pA @ 5V
High output current capability: 30mA
Low quiescent current: 20µA
High CMRR and PSRR: 75dB CMRR, 80dB PSRR
Fast propagation delay: 10µs
Product Advantages
Extremely low power usage enhances battery life in portable applications
High precision with low input bias and offset voltage
Robust output drive capacity
Key Technical Parameters
Supply Voltage Range: 2.7V to 15V, ±1.35V to ±7.5V
Proprietary Output Type: Open-Drain
Operating Temperature: -40°C to 85°C
Package: 8-TSSOP, 8-MSOP
Quality and Safety Features
Operates reliably over a wide temperature range
High CMRR and PSRR ensure stable operation against power supply variations and common-mode noise
Compatibility
Compatible with TTL, MOS, and CMOS logic systems due to open-drain output type
Application Areas
Signal processing
Data acquisition systems
Sensing applications in consumer and industrial electronics
Product Lifecycle
Obsolete status
Users should seek replacements or consider latest upgrades for future designs
Several Key Reasons to Choose This Product
Precision performance for sensing and comparison applications
Extremely low input current and power consumption suitable for battery-powered devices
Suitable for harsh operating environments due to wide temperature range operability
High-voltage flexibility with dual supply voltage ranges up to 15V
Reliable output with robust current driving capabilities
