Manufacturer Part Number
MSP430F5510IRGZR
Manufacturer
Texas Instruments
Introduction
The MSP430F5510IRGZR is a 16-bit embedded microcontroller from Texas Instruments, designed for low-power and high-performance applications.
Product Features and Performance
Core Processor: MSP430 CPUXV2
Core Size: 16-Bit
Operating Speed: 25 MHz
Connectivity options include I2C, IrDA, LINbus, SCI, SPI, UART/USART, USB
Peripherals include Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Size: 32KB FLASH
RAM Size: 6K x 8
A/D Converters: 8 x 10-bit
Internal Oscillator
Operating Temperature Range: -40°C to 85°C
Product Advantages
High integration with multiple communication interfaces
Efficient power management capable of running with low voltage supply
Robust peripheral set supporting complex functionalities
Key Technical Parameters
Number of I/O: 31
Voltage Supply: 1.8V to 3.6V
Data Converters: A/D 8x10b
Program Memory: 32KB FLASH
RAM Memory: 6K x 8
Surface Mount, 48-VQFN (7x7) package
Quality and Safety Features
Brown-out Detect/Reset for voltage monitoring
Watchdog Timer (WDT) for system integrity check
Compatibility
Seamless integration with existing architectures courtesy of comprehensive connectivity options
Application Areas
Consumer Electronics
Industrial Automation
Portable Medical Devices
Energy Management
Product Lifecycle
Status: Active
Continuously supported with no near-term discontinuation expected
Several Key Reasons to Choose This Product
Provides robust connectivity solutions suitable for various complex applications.
Offers advanced control and monitoring capabilities via enhanced peripheral set.
Efficient in power management, suitable for battery-operated devices.
Suitable for a broad range of temperatures, enhancing reliability in harsh environments.
Enhanced data handling and processing with built-in A/D converters and large memory capacity.
