Manufacturer Part Number
THS4032IDGNR
Manufacturer
Texas Instruments
Introduction
Dual-channel instrumentation amplifier
Suitable for a wide range of instrumentation and measurement applications
Product Features and Performance
Wide gain bandwidth of 120 MHz
Fast slew rate of 100 V/μs
Low input offset voltage of 500 μV
Low input bias current of 3 μA
Wide supply voltage range of 9 V to 32 V
Capable of driving heavy loads with 90 mA output current per channel
Product Advantages
Excellent AC and DC performance
Capable of driving heavy loads
Wide operating temperature range of -40°C to 85°C
Small 8-HVSSOP package
Key Technical Parameters
Gain Bandwidth Product: 120 MHz
Voltage Supply Span (Min/Max): 9 V to 32 V
Current Supply: 8.5 mA per channel
Slew Rate: 100 V/μs
Voltage Input Offset: 500 μV
Amplifier Type: Voltage Feedback
Current Output / Channel: 90 mA
Current Input Bias: 3 μA
-3dB Bandwidth: 100 MHz
Quality and Safety Features
RoHS3 compliant
8-HVSSOP package for reliable surface mount assembly
Compatibility
Compatible with a wide range of instrumentation and measurement applications
Application Areas
Instrumentation and measurement applications
Data acquisition systems
Industrial control systems
Medical equipment
Product Lifecycle
Currently in production
Replacements and upgrades available from Texas Instruments
Key Reasons to Choose This Product
Excellent AC and DC performance with wide bandwidth and fast slew rate
Capable of driving heavy loads with high output current
Wide operating temperature range for reliable operation in various environments
Small footprint 8-HVSSOP package for efficient board layout
