Manufacturer Part Number
TMS320LF2406APZA
Manufacturer
Texas Instruments
Introduction
The TMS320LF2406APZA is a 16-Bit Digital Signal Processor from Texas Instruments, part of the C2000™ C24x Series, focusing on embedded control applications.
Product Features and Performance
Core Processor: C2xx DSP core
Speed: Operates at 40MHz clock speed
Connectivity: Features CANbus, SCI, SPI, UART/USART for versatile peripheral interfacing
Peripherals: Power-on Reset (POR), Pulse Width Modulation (PWM), Watchdog Timer (WDT)
Program Memory Size: 64KB FLASH
RAM Size: 5K x 8
Data Converters: Equipped with A/D 16x10b for accurate analog to digital conversions
Oscillator: Integrated internal oscillator
Operating Temperature Range: -40°C to 85°C ensuring reliability across various environments
Product Advantages
Adequate program memory and RAM for complex applications
Advanced control-oriented peripherals suitable for motor control, automation, etc.
Scalable C2000™ microcontroller platform for future enhancements
Robust temperature range ideal for industrial applications
Key Technical Parameters
Core Size: 16-Bit microcontroller
Number of I/O: 41 input/output pins
Voltage Supply (Vcc/Vdd): Operational between 3V and 3.6V
Mounting Type: Surface Mount for compact PCB designs
Supplier Device Package: 100-LQFP (14x14) for a standardized layout
Package / Case: Delivered in a 100-Pin Low Profile Quad Flat Package
Quality and Safety Features
Extended temperature support ensures reliability under stress
Watchdog Timer for system integrity and error handling
Power-on Reset helps in safe power cycles and start-ups
Compatibility
100-LQFP package common across multiple devices for compatibility with standard PCB designs
SPI, UART/USART, and CAN interfaces compatible with a variety of peripheral components and systems
Application Areas
Industrial control systems
Motor control
Power electronics
Automation
Product Lifecycle
Product Status: Active
Not nearing discontinuation
Upgrades and replacements usually available within Texas Instruments C2000™ Series
Several Key Reasons to Choose This Product
Robust speed and memory capabilities facilitate complex and demanding applications
Advanced connectivity options provide flexibility in system design
Diverse embedded control features support a wide range of applications
Active product status with Texas Instruments' strong support and resources
Proven quality and safety features ensure reliable, long-term operation
Compatibility with industry-standard packages and interfaces simplifies product integration
TMS320LF2406PZATexas Instruments
TMS320LF2406APZARTexas Instruments
TMS320LF2403APAGSTexas InstrumentsIC MCU 16BIT 32KB FLASH 64TQFP
TMS320LF2403APAGSRTexas InstrumentsIC MCU 16BIT 32KB FLASH 64TQFP
