Manufacturer Part Number
TPS76701QPWPR
Manufacturer
Texas Instruments
Introduction
The TPS76701QPWPR is an adjustable, low dropout linear voltage regulator ideal for applications requiring a regulated output from an unregulated input source.
Product Features and Performance
Adjustable output voltage ranging from 1.5V to 5.5V
Capable of delivering up to 1A of output current
Low quiescent current of 125 µA enhances power efficiency
Power Supply Rejection Ratio (PSRR) of 60dB at 1kHz ensures stable output under noisy conditions
Integrated features include enable and reset controls for improved system management
Protection mechanisms for over current, over temperature, and reverse polarity safeguard the system
Product Advantages
Versatile adjustable output for a wide range of applications
High efficiency with low quiescent current
Robust protection features enhance system reliability
Key Technical Parameters
Input Voltage (Max): 10V
Output Voltage (Min): 1.5V
Output Voltage (Max): 5.5V
Current Output: 1A
Current Quiescent (Iq): 125 µA
PSRR: 60dB (1kHz)
Quality and Safety Features
Over current protection
Over temperature protection
Reverse polarity protection
Compatibility
Surface mount technology compatible with 20-PowerTSSOP packaging
Application Areas
Consumer electronics
Telecommunication equipment
Computing systems
Industrial controls
Product Lifecycle
Currently active, not nearing discontinuation
Ongoing availability of replacements and upgrades
Several Key Reasons to Choose This Product
Reliable performance under variable input conditions
Low power consumption enhances battery life
Comprehensive protection features prevent damage and downtime
Adjustable voltage output for greater application flexibility
High PSRR ensures stability in fluctuating power environments
