Manufacturer Part Number
AT45DB081B-CNU
Manufacturer
Microchip Technology
Introduction
The AT45DB081B-CNU is a non-volatile FLASH memory device with a capacity of 8 Mbit, designed for storing code and data for wide-ranging electronic applications.
Product Features and Performance
Non-Volatile FLASH Memory
8Mbit Memory Size
Memory Organization of 264 Bytes x 4096 Pages
SPI Memory Interface for simple integration with microcontrollers
Maximum Clock Frequency of 20 MHz for fast operation
Write Cycle Time Word, Page of 14ms for efficient programming
Operating Temperature Range from -40°C to 85°C, suitable for diverse environments
Product Advantages
SPI interface facilitates easy connection with a broad array of microcontrollers and processors.
High density of 8Mbit allows for substantial data storage in compact devices.
Fast data access and programming speeds support efficient system performance.
Key Technical Parameters
Memory Size: 8Mbit
Memory Organization: 264 Bytes x 4096 Pages
Memory Interface: SPI
Clock Frequency: 20 MHz
Supply Voltage: 2.7V ~ 3.6V
Operating Temperature: -40°C ~ 85°C (TC)
Quality and Safety Features
Designed for high reliability and stability across the operating temperature range.
Robust packaging suitable for surface mount and harsh environments.
Compatibility
SPI interface ensures compatibility with a wide range of microcontroller and processor architectures.
Application Areas
Embedded Systems
Consumer Electronics
IoT Devices
Industrial Control Systems
Product Lifecycle
Obsolete status, indicating discontinuation by the manufacturer.
Potential availability of replacements or upgrades should be verified with Microchip Technology for ongoing projects.
Several Key Reasons to Choose This Product
High data storage capacity in a compact format.
SPI interface compatibility eases integration challenges.
Suitable for a wide range of temperatures, ensuring reliability in varied environments.
Fast read-write cycle time enhances device performance.
Obsolescence status requires consideration for long-term projects but may offer cost benefits for immediate needs.
