A1015 PNP Transistor: Pinout and Specifications

The A1015 is a versatile PNP transistor designed for low voltage and power applications, making it reliable and efficient for a range of electronic projects. It is useful in amplifiers and switches, where it delivers steady and consistent performance. This article explores the A1015's characteristics, practical uses, and how it stands out in handling moderate voltages and currents efficiently.

Catalog

1. What is the A1015 Transistor?

2. A1015 Pin Configuration

3. A1015 Symbol, Footprint, and CAD Model

4. Features of the A1015

5. A1015 Technical Specifications

6. Package for A1015

7. A1015 Manufacturer Information

What is the A1015 Transistor?

The A1015, a PNP transistor, showcases notable strength in managing moderate voltages and currents, positioning it as a highly adaptable component in both switching and amplification duties. This device efficiently handles up to 50 volts between the collector and emitter, supports collector currents of up to 150mA, and embraces its role in contexts demanding dependable electrical performance.

A1015 Pin Configuration

Pinout A1015

A1015 Symbol, Footprint, and CAD Model

A1015 Symbol

A1015 Footprint

A1015 CAD Model

Features of the A1015

• Handles up to 50V across collector-emitter junctions.

• Supports collector currents up to 150mA.

• Offers stable circuit performance with smooth hFE (current gain) characteristics.

• Pairs effectively with complementary transistors like the C1815 for push-pull amplifier systems.

• Designed to handle power levels up to 200mW, suitable for low-power applications.

• Ideal for audio amplification, signal switching, and conditioning in energy-efficient circuits.

A1015 Technical Specifications

Type	Parameter
Package / Case	SOT-23 (SOT-23-3)
Packaging	Tape & Reel (TR)
Transistor Type	PNP
RoHS Status	RoHS Compliant
Current - Collector (Ic) (Max)	150mA
Power - Max	200mW
Voltage - Collector Emitter Breakdown (Max)	50V

Package for A1015

A1015 Package

A1015 Manufacturer Information

Changjiang Electronics Technology, born in 1972, has emerged as a pioneering force within China's IC packaging and testing sectors. This high-tech entity has cultivated an impressive range of advanced services, encompassing chip testing alongside comprehensive packaging solutions. Their steady progress cements their stature in the industry, highlighted by numerous accolades. These recognitions span titles of excellence in electronics, leadership within national engineering labs, and technological centers distinction. The firm’s ardent dedication to excellence is evident in its focus on sustainability and ethical conduct. A commitment to sustainable development, along with the continuous enhancement of resource management techniques, not only aligns with global environmental standards but also fortifies brand integrity.
