HomeProductsConnectors, InterconnectsRectangular Connectors - Headers, Male Pins39-30-6167
39-30-6167 Image
39-30-6167 Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

39-30-6167 - Affinity Medical Technologies - a Molex company

Manufacturer Part Number
39-30-6167
Manufacturer
Molex
Allelco Part Number
98D-39-30-6167
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
CONN HEADER 16POS 4.2MM VERT TIN
Package
Data sheet
1.39-30-6167.pdf ...
RoHs Status
Lead free / RoHS Compliant
Compare
Our certification
In stock: 34638
  • Unit Price: $0.949
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $0.949 $0.95
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

39-30-6167 Tech Specifications
Affinity Medical Technologies - a Molex company - 39-30-6167 technical specifications, attributes, parameters and parts with similar specifications to Affinity Medical Technologies - a Molex company - 39-30-6167

Product Attribute Attribute Value
Manufacturer Molex
Voltage Rating -
Termination Solder
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Series Mini-Fit Jr 5566
Row Spacing - Mating 0.165" (4.20mm)
Pitch - Mating 0.165" (4.20mm)
Packaging Tray
Overall Contact Length -
Other Names 003930-6167
0039306167
03930-6167
039306167
3930-6167
39306167
5566-16B2S
WM17752
Operating Temperature -
Number of Rows 2
Number of Positions Loaded All
Number of Positions 16
Mounting Type Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Material Flammability Rating UL94 V-2
Mated Stacking Heights -
Manufacturer Standard Lead Time 9 Weeks
Product Attribute Attribute Value
Lead Free Status / RoHS Status Lead free / RoHS Compliant
Insulation Material Polyamide (PA66), Nylon 6/6
Insulation Height 0.504" (12.80mm)
Insulation Color Natural
Ingress Protection -
Features Board Lock
Fastening Type Locking Ramp
Detailed Description Connector Header Through Hole 16 position 0.165" (4.20mm)
Current Rating -
Contact Type Male Pin
Contact Shape Square
Contact Material Brass
Contact Length - Post 0.138" (3.50mm)
Contact Length - Mating -
Contact Finish Thickness - Post 100.0µin (2.54µm)
Contact Finish Thickness - Mating 100.0µin (2.54µm)
Contact Finish - Post Tin
Contact Finish - Mating Tin
Connector Type Header
Applications General Purpose, Industrial, Telecommunications

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status Lead free / RoHS Compliant

Parts with Similar Specifications

The three parts on the right have similar specifications to Affinity Medical Technologies - a Molex company 39-30-6167

Product Attribute 39-30-6147 39-30-6127 39-30-6107 39-30-6187
Part Number 39-30-6147 39-30-6127 39-30-6107 39-30-6187
Manufacturer Affinity Medical Technologies - a Molex company Affinity Medical Technologies - a Molex company Affinity Medical Technologies - a Molex company Affinity Medical Technologies - a Molex company
Lead Free Status / RoHS Status - - - -
Series - - - -
Style - - - -
Contact Type - - - -
Number of Positions Loaded - - - -
Applications - - - -
Number of Rows - - - -
Mounting Type - Surface Mount Through Hole Surface Mount
Overall Contact Length - - - -
Ingress Protection - - - -
Mated Stacking Heights - - - -
Shrouding - - - -
Packaging - - - -
Insulation Color - - - -
Termination - - - -
Contact Finish - Post - - - -
Detailed Description - - - -
Operating Temperature - -40°C ~ 85°C 0°C ~ 70°C -40°C ~ 85°C
Insulation Material - - - -
Contact Finish - Mating - - - -
Features - - - Simultaneous Sampling
Number of Positions - - - -
Contact Finish Thickness - Post - - - -
Other Names - - - -
Contact Material - - - -
Contact Finish Thickness - Mating - - - -
Fastening Type - - - -
Manufacturer Standard Lead Time - - - -
Contact Shape - - - -
Pitch - Mating - - - -
Row Spacing - Mating - - - -
Material Flammability Rating - - - -
Contact Length - Post - - - -
Current Rating - - - -
Contact Length - Mating - - - -
Voltage Rating - - - -
Insulation Height - - - -
Moisture Sensitivity Level (MSL) - - - -
Connector Type - - - -

39-30-6167 Datasheet PDF

Download 39-30-6167 pdf datasheets and Affinity Medical Technologies - a Molex company documentation for 39-30-6167 - Affinity Medical Technologies - a Molex company.

Datasheets
5556-001 Prod Spec.pdf 39-30-0yyy,6yyy Drawing.pdf
