Specifications
TR2-S505SC-1-R Tech Specifications
Eaton - Electronics Division - TR2-S505SC-1-R technical specifications, attributes, parameters and parts with similar specifications to Eaton - Electronics Division - TR2-S505SC-1-R
| Product Attribute |
Attribute Value
| |
| Manufacturer |
Coiltronics (Eaton) |
|
| Voltage Rating - AC |
250 V |
|
| Size / Dimension |
0.205' Dia x 0.787' L (5.20mm x 20.00mm) |
|
| Series |
S505 |
|
| Response Time |
Slow Blow |
|
| Package / Case |
5mm x 20mm (Axial) |
|
| Package |
Tape & Reel (TR) |
|
| Operating Temperature |
- |
|
| Product Attribute |
Attribute Value
| |
| Mounting Type |
Through Hole |
|
| Melting I²t |
1.28 |
|
| Fuse Type |
Cartridge, Ceramic |
|
| DC Cold Resistance |
0.1401 Ohms |
|
| Current Rating (Amps) |
1 A |
|
| Color |
- |
|
| Breaking Capacity @ Rated Voltage |
1.5kA |
|
| Approval Agency |
BSI, CCC/CQC, CSA, cURus, IMQ, KC, PSE/JET, SEMKO, VDE |
|
