Specifications
WCL3225-R33-R Tech Specifications
Eaton - Electronics Division - WCL3225-R33-R technical specifications, attributes, parameters and parts with similar specifications to Eaton - Electronics Division - WCL3225-R33-R
| Product Attribute |
Attribute Value
| |
| Manufacturer |
Coiltronics (Eaton) |
|
| Type |
Drum Core, Wirewound |
|
| Tolerance |
±5% |
|
| Supplier Device Package |
1210 |
|
| Size / Dimension |
0.138" L x 0.114" W (3.50mm x 2.90mm) |
|
| Shielding |
Unshielded |
|
| Series |
WCL3225 |
|
| Ratings |
- |
|
| Q @ Freq |
20 @ 25.2MHz |
|
| Package / Case |
1210 (3225 Metric) |
|
| Package |
Tape & Reel (TR) |
|
| Product Attribute |
Attribute Value
| |
| Operating Temperature |
-40°C ~ 85°C |
|
| Mounting Type |
Surface Mount |
|
| Material - Core |
Ceramic |
|
| Inductance Frequency - Test |
25.2 MHz |
|
| Inductance |
330 nH |
|
| Height - Seated (Max) |
0.089" (2.25mm) |
|
| Frequency - Self Resonant |
520MHz |
|
| Features |
- |
|
| DC Resistance (DCR) |
300mOhm Max |
|
| Current Rating (Amps) |
450 mA |
|
| Current - Saturation (Isat) |
- |
|
