Specifications
35HDBN Tech Specifications
Switchcraft Inc. - 35HDBN technical specifications, attributes, parameters and parts with similar specifications to Switchcraft Inc. - 35HDBN
| Product Attribute |
Attribute Value
| |
| Manufacturer |
Conxall / Switchcraft |
|
| Voltage - Rated |
250VAC, 140VDC |
|
| Thread Size |
- |
|
| Termination |
Solder |
|
| Signal Lines |
Stereo (3 Conductor, TRS) |
|
| Shielding |
Unshielded |
|
| Series |
35HD |
|
| Panel Hole Size |
- |
|
| Package |
Bulk |
|
| Operating Temperature |
0°C ~ 66°C |
|
| Number of Positions/Contacts |
3 Conductors, 3 Contacts |
|
| Mounting Type |
Free Hanging (In-Line) |
|
| Mating Length/Depth |
0.560' (14.20mm) |
|
| Internal Switch(s) |
Does Not Contain Switch |
|
| Product Attribute |
Attribute Value
| |
| Insulation Color |
- |
|
| Industry Recognized Mating Diameter |
3.50mm (0.141', 1/8', Mini Plug) - Headphone |
|
| Includes |
3 pcs - 1 Connector, 1 Handle, 1 Insulator Tube |
|
| Housing Material |
Brass |
|
| Gender |
Male |
|
| Features |
- |
|
| Current Rating (Amps) |
4 A |
|
| Contact Material - Plating |
Tin |
|
| Contact Material |
Brass |
|
| Connector Type |
Phone Plug |
|
| Cable Opening |
0.290' (7.37mm) |
|
| Body Material |
Brass |
|
| Body Color |
Silver, Black |
|
| Actual Diameter |
0.138' (3.50mm) |
|
