Manufacturer Part Number
B514F-2
Manufacturer
sensata-technologies
Introduction
The B514F-2 is a high-performance, single-phase thyristor module from Sensata Technologies. It features a bridge configuration with two SCRs and two diodes, designed for a wide range of industrial and power control applications.
Product Features and Performance
Voltage rating of 1.2 kV for off-state operation
Gate trigger voltage (Vgt) of 2.5 V (max)
Gate trigger current (Igt) of 60 mA (max)
Non-repetitive surge current (Itsm) of 250 A at 60 Hz
Operating temperature range of -40°C to 125°C (junction temperature)
Product Advantages
Robust and reliable performance for demanding applications
High voltage and current handling capabilities
Compact and efficient module design
Chassis mount configuration for easy installation
Key Reasons to Choose This Product
Exceptional power handling and thermal management
Proven reliability and long service life
Versatile for use in a variety of industrial applications
Backed by Sensata's reputation for quality and innovation
Quality and Safety Features
Designed and manufactured to high quality standards
Isolation barriers for enhanced safety and protection
Rigorous testing and validation processes
Compatibility
The B514F-2 is compatible with a wide range of industrial and power control applications, including:
Motor control systems
Power conversion and regulation
Heating and lighting control
Industrial automation and machinery
Application Areas
Industrial automation and control
Power electronics and power conversion
Motor drives and variable speed control
Lighting and heating control systems
Product Lifecycle
The B514F-2 is an obsolete product, and Sensata Technologies no longer manufactures this specific model. However, there are several alternative and equivalent models available in the market that may serve as suitable replacements. Customers are advised to contact our website's sales team for more information on the availability of alternative products and to discuss their specific requirements.
