HomeProductsSwitchesKeypad Switches09-0A72.3142
09-0A72.3142 Image
09-0A72.3142 Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

09-0A72.3142 - EAO

Manufacturer Part Number
09-0A72.3142
Manufacturer
EAO
Allelco Part Number
98D-09-0A72.3142
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
SWITCH KEYPAD 6 KEY RED ILLUM
Package
Box
Data sheet
1.09-0A72.3142.pdf ...
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 37792
  • Unit Price: $431.251
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $431.251 $431.25
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

09-0A72.3142 Tech Specifications
EAO - 09-0A72.3142 technical specifications, attributes, parameters and parts with similar specifications to EAO - 09-0A72.3142

Product Attribute Attribute Value
Manufacturer EAO
Termination Style Cable with Connector
Switch Type Snap Dome
Series 09
Panel Cutout Dimensions Rectangular - 107.10mm x 68.80mm
Package Box
Output Type Matrix
Operational Life 250,000 Cycles
Operating Temperature -40°C ~ 85°C
Number of Keys 6
Mounting Type Panel Mount, Front
Matrix (Columns x Rows) 3 x 2
Product Attribute Attribute Value
Legend Type Fixed
Legend Color White
Legend -
Key Type -
Key Color Black
Ingress Protection IP67 - Dust Tight, Waterproof
Illumination Voltage (Nominal) -
Illumination Illuminated - White
Features -
Contact Rating @ Voltage 0.03A @ 32VDC
Approval Agency -

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) Not Applicable

Parts with Similar Specifications

The three parts on the right have similar specifications to EAO 09-0A72.3142

Product Attribute 09-0A72.3142 09-0A72.3132 09-0A22.1111 09-0A12.1111
Part Number 09-0A72.3142 09-0A72.3132 09-0A22.1111 09-0A12.1111
Manufacturer EAO EAO EAO EAO
Termination Style Cable with Connector Cable with Connector Cable with Connector Cable with Connector
Key Type - - - -
Matrix (Columns x Rows) 3 x 2 3 x 2 3 x 2 3 x 2
Series 09 09 09 09
Ingress Protection IP67 - Dust Tight, Waterproof IP67 - Dust Tight, Waterproof IP67 - Dust Tight, Waterproof IP67 - Dust Tight, Waterproof
Illumination Illuminated - White Illuminated - White Illuminated - White Illuminated - White
Features - - - -
Package Box Box Box Box
Mounting Type Panel Mount, Front Panel Mount, Front Panel Mount, Front Panel Mount, Front
Approval Agency - - - -
Contact Rating @ Voltage 0.03A @ 32VDC 0.03A @ 32VDC 0.03A @ 32VDC 0.03A @ 32VDC
Legend Type Fixed Fixed Fixed Fixed
Output Type Matrix Matrix Matrix Matrix
Legend Color White White White White
Legend - - - -
Key Color Black Black Black Black
Number of Keys 6 6 6 6
Illumination Voltage (Nominal) - - - -
Operational Life 250,000 Cycles 250,000 Cycles 250,000 Cycles 250,000 Cycles
Operating Temperature -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C -40°C ~ 85°C
Switch Type Snap Dome Snap Dome Snap Dome Snap Dome
Panel Cutout Dimensions Rectangular - 107.10mm x 68.80mm Rectangular - 107.10mm x 68.80mm Rectangular - 107.10mm x 68.80mm Rectangular - 107.10mm x 68.80mm
