C5P0206N-RA - Electroswitch

Name: Electroswitch C5P0206N-RA
Brand: Electroswitch
SKU: C5P0206N-RA
Price: 5.85 USD
Availability: InStock
Rating: 5 (4 reviews)

Manufacturer Part Number: C5P0206N-RA

Manufacturer: Electroswitch

Allelco Part Number: 98D-C5P0206N-RA

Warranty: 1 Year Allelco Warranty - Find out more

Parts Description: SWITCH ROTARY 2-6POS 1A 125V

Package: Bulk

Data sheet: 1.C5P0206N-RA.pdf ...

Datasheets
C5,C6 Series.pdf

Other Related Documents
C5, C6 Series Adjustable Stop Instr.pdf

RoHs Status: RoHS Compliant

~~Compare~~

Our certification

In stock: 35832

Unit Price: $15.44
Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity	Unit Price	Ext. Price
1+	$15.44	$15.44
200+	$6.16	$1,232.00
500+	$5.95	$2,975.00
1000+	$5.85	$5,850.00

The above prices does not include taxes and freight rates, which will be calculated on the order pages.

EXPRESS OPTION

Payment method

Our certification

Specifications

C5P0206N-RA Tech Specifications
Electroswitch - C5P0206N-RA technical specifications, attributes, parameters and parts with similar specifications to Electroswitch - C5P0206N-RA

Product Attribute	Attribute Value
Manufacturer	Electroswitch
Voltage Rating - DC	28 V
Voltage Rating - AC	125 V
Termination Style	PC Pin
Series	C5
Panel Cutout Dimensions	Circular - 9.78mm Dia
Package	Bulk
Number of Positions	2 ~ 6
Number of Poles per Deck	2
Number of Decks	1
Mounting Type	Panel Mount, Through Hole
Index Stops	Adjustable

Product Attribute	Attribute Value
Features	Sealed
Depth Behind Panel	14.10mm
Current Rating (Amps)	1A (AC/DC)
Contact Timing	Non-Shorting (BBM)
Contact Material	Brass
Contact Finish	Silver
Circuit per Deck	DP6T
Base Product Number	C5P0206
Angle of Throw	30°
Actuator Type	Flatted (6.35mm Dia)
Actuator Length	14.29mm

Environmental & Export Classifications

ATTRIBUTE	DESCRIPTION
RoHs Status	RoHS Compliant
Moisture Sensitivity Level (MSL)	Not Applicable
REACH Status	Vendor Undefined
ECCN	EAR99
HTSUS	8536.50.9020

Parts with Similar Specifications

The three parts on the right have similar specifications to Electroswitch C5P0206N-RA

Product Attribute
Part Number	C5P0206N-A	C5P0112N-RA	C5P0403N-RA	C5P0304N-RA
Manufacturer	Electroswitch	Electroswitch	Electroswitch	Electroswitch
Number of Decks	-	-	-	-
Contact Finish	-	-	-	-
Package	-	Tape & Reel (TR)	Tube	Tape & Reel (TR)
Current Rating (Amps)	-	-	-	-
Panel Cutout Dimensions	-	-	-	-
Index Stops	-	-	-	-
Voltage Rating - DC	-	-	-	-
Voltage Rating - AC	-	-	-	-
Depth Behind Panel	-	-	-	-
Actuator Type	-	-	-	-
Angle of Throw	-	-	-	-
Number of Poles per Deck	-	-	-	-
Number of Positions	-	-	-	-
Features	-	-	-	Simultaneous Sampling
Base Product Number	-	DAC34H84	MAX500	ADS62P42
Contact Material	-	-	-	-
Series	-	-	-	-
Termination Style	-	-	-	-
Circuit per Deck	-	-	-	-
Actuator Length	-	-	-	-
Contact Timing	-	-	-	-
Mounting Type	-	Surface Mount	Through Hole	Surface Mount

C5P0206N-RA Datasheet PDF

Download C5P0206N-RA pdf datasheets and Electroswitch documentation for C5P0206N-RA - Electroswitch.

Datasheets: C5,C6 Series.pdf
Other Related Documents: C5, C6 Series Adjustable Stop Instr.pdf
