Manufacturer Part Number
CD4081BNSR
Manufacturer
Texas Instruments
Introduction
The CD4081BNSR is a member of the 4000B series logic family that features quadruple 2-input AND gates.
Product Features and Performance
Four independent 2-input AND gates in a single IC
Designed for medium-speed operation
Increased output drive capability
Product Advantages
High noise immunity characteristic of CMOS devices
Low power consumption
Wide range of operating voltages from 3V to 18V
Key Technical Parameters
Logic Type: AND Gate
Number of Circuits: 4
Number of Inputs per Gate: 2
Voltage - Supply: 3V to 18V
Current - Quiescent (Max): 1 µA
Current - Output High, Low: 3.4mA
Input Logic Level - Low: 1.5V to 4V
Input Logic Level - High: 3.5V to 11V
Max Propagation Delay: 90ns at 15V, 50pF
Operating Temperature: -55°C to 125°C
Quality and Safety Features
Constructed with silicon gate CMOS technology
Reliable performance in extended temperature range
Compatibility
Compatible with other CMOS and TTL logic families
Application Areas
Utility in computers and computer peripherals
Instrumentation and control systems
Data processing
Signal generators
Product Lifecycle
Active product status implies ongoing manufacture and support
Not approaching discontinuation; replacements or upgrades typically available
Several Key Reasons to Choose This Product
Proven reliability from Texas Instruments
Ability to interface with multiple logic families
Supports wide voltage operation range for flexible usage in various circuits
Possesses high immunity against electrical noise
Low power consumption suited for battery-operated applications
Available in surface-mount package for compact circuit designs
High-temperature operational capability allows for use in harsh environments
