Manufacturer Part Number
CSD17507Q5A
Manufacturer
Texas Instruments
Introduction
The CSD17507Q5A is a high-performance N-channel MOSFET transistor from Texas Instruments, part of the NexFET series.
Product Features and Performance
30V drain-to-source voltage rating
8mΩ maximum on-resistance at 11A, 10V
13A continuous drain current at 25°C
65A continuous drain current at 100°C
530pF maximum input capacitance at 15V
3W maximum power dissipation at 25°C
Operating temperature range from -55°C to 150°C
Product Advantages
Excellent on-resistance performance for efficient power conversion
High current handling capability
Compact 8-VSONP (5x6) package
Key Technical Parameters
Drain-to-Source Voltage (Vdss): 30V
Gate-to-Source Voltage (Vgs): ±20V
On-Resistance (Rds(on)): 10.8mΩ @ 11A, 10V
Drain Current (Id): 13A @ 25°C, 65A @ 100°C
Input Capacitance (Ciss): 530pF @ 15V
Power Dissipation: 3W @ 25°C
Quality and Safety Features
RoHS3 compliant
ESD protection
Compatibility
Compatible with a wide range of electronic circuits and power management applications
Application Areas
Suitable for use in power supplies, motor drives, and other power conversion applications
Product Lifecycle
Currently in production
Replacement or upgrade options may be available in the future
Key Reasons to Choose This Product
Excellent on-resistance and high current handling for efficient power conversion
Compact package size and surface-mount design for space-constrained applications
Wide operating temperature range for use in various environmental conditions
RoHS3 compliance for environmentally-friendly design
