Manufacturer Part Number
ISO7763DBQR
Manufacturer
Texas Instruments
Introduction
Digital isolator with 6 channels
Provides galvanic isolation between different circuit sections
Product Features and Performance
Voltage isolation up to 3000Vrms
Common mode transient immunity of at least 85kV/s
Data rate up to 100Mbps
Very fast propagation delay (max 16ns)
Low pulse width distortion (max 4.9ns)
Operates over wide temperature range (-55°C to 125°C)
Product Advantages
Compact 16-SSOP package
Surface mount design
Capacitive coupling technology for isolation
Key Technical Parameters
6 independent unidirectional isolation channels
25V to 5.5V supply voltage range
RoHS3 compliant
Quality and Safety Features
ROHS3 compliant
Isolation voltage up to 3000Vrms
Compatibility
Can be used in a wide range of applications requiring galvanic isolation
Application Areas
Industrial automation
Power supplies
Motor drives
Medical equipment
Instrumentation
Data acquisition systems
Product Lifecycle
Current production part, no plans for discontinuation
Replacement or upgrade options available from Texas Instruments
Key Reasons to Choose
Robust isolation performance
High data rate and fast response time
Wide operating temperature range
Small, space-saving package
RoHS3 compliance for restricted environments
