Image may be representation.
See specifications for product details.

~~Favorite~~

EXPRESS OPTION

Payment method

REF3112AIDBZR - Texas Instruments

Name: Texas Instruments REF3112AIDBZR
Brand: Texas Instruments
SKU: REF3112AIDBZR
Price: 0.272 USD
Availability: InStock
Rating: 5 (2 reviews)

Manufacturer Part Number: REF3112AIDBZR

Manufacturer: Texas Instruments

Allelco Part Number: 32D-REF3112AIDBZR

Warranty: 1 Year Allelco Warranty - Find out more

Parts Description: IC VREF SERIES 0.2% SOT23-3

Package: SOT-23-3

Data sheet: 1.REF3112AIDBZR.pdf ...

HTML Datasheet
REF3112/20/25/30/33/40.pdf

PCN Assembly/Origin
REF3yyy 13/Nov/2019.pdf

PCN Design/Specification
Wire Chg 19/Mar/2016.pdf

RoHs Status: ROHS3 Compliant

~~Compare~~

Our certification

In stock: 32690

Unit Price: $0.529
Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity	Unit Price	Ext. Price
1+	$0.529	$0.53
10+	$0.435	$4.35
30+	$0.388	$11.64
100+	$0.342	$34.20
500+	$0.285	$142.50
1000+	$0.272	$272.00

The above prices does not include taxes and freight rates, which will be calculated on the order pages.

EXPRESS OPTION

Payment method

Our certification

Specifications

REF3112AIDBZR Tech Specifications
Texas Instruments - REF3112AIDBZR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - REF3112AIDBZR

Product Attribute	Attribute Value
Manufacturer	Texas Instruments
Voltage - Output (Min/Fixed)	1.25V
Voltage - Input	1.8V ~ 5.5V
Tolerance	±0.2%
Temperature Coefficient	20ppm/°C
Supplier Device Package	SOT-23-3
Series	-
Reference Type	Series
Package / Case	TO-236-3, SC-59, SOT-23-3

Product Attribute	Attribute Value
Package	Tape & Reel (TR)
Output Type	Fixed
Operating Temperature	-40°C ~ 125°C (TA)
Noise - 10Hz to 10kHz	24µVrms
Noise - 0.1Hz to 10Hz	17µVp-p
Mounting Type	Surface Mount
Current - Supply	135µA
Current - Output	10 mA
Base Product Number	REF3112

Environmental & Export Classifications

ATTRIBUTE	DESCRIPTION
RoHs Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001

Parts Introduction

Manufacturer Part Number

REF3112AIDBZR

Manufacturer

Texas Instruments

Introduction

Precision low-power voltage reference IC for power management applications

Product Features and Performance

Series voltage reference technology

Fixed 1.25V output voltage

10 mA output current capability

±0.2% tolerance for high accuracy

Stable temperature coefficient at 20ppm/°C

Low output noise characteristics at 17µVp-p (0.1Hz to 10Hz) and 24µVrms (10Hz to 10kHz)

Wide input voltage range from 1.8V to 5.5V

Low supply current requirement at 135µA

Product Advantages

High precision voltage output for reliable reference

Low power consumption suitable for battery-operated devices

Low noise output for sensitive applications

High temperature operational range allowing for use in various environments

Compact SOT-23-3 package for space-constrained applications

Key Technical Parameters

Output Voltage 1.25V

Output Current 10 mA

Tolerance ±0.2%

Temperature Coefficient 20ppm/°C

Input Voltage Range 1.8V ~ 5.5V

Supply Current 135µA

Quality and Safety Features

Robust operation from -40°C to +125°C

Industry-standard SOT-23-3 packaging for reliability

Compatibility

Compatible with a variety of circuits requiring a stable voltage reference

Application Areas

Precision analog to digital conversions

Power supply monitoring

Portable and battery-powered equipment

Data acquisition systems

Industrial automation

Product Lifecycle

Active product with support and availability of replacements or upgrades

Several Key Reasons to Choose This Product

Highly accurate and stable voltage for critical applications

Low power consumption enhances battery life in portable devices

Industry-standard package suitable for automated assembly processes

Wide operating temperature range for use in harsh environments

Supported by Texas Instruments' renowned quality and reliability

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments REF3112AIDBZR

Product Attribute
Part Number	REF3112AIDBZRG4	REF3112AIDBZTG4	REF3120AIDBZRG4	REF3120AIDBZR
Manufacturer	Texas Instruments	Texas Instruments	Texas Instruments	Texas Instruments
Package / Case	-	196-LFBGA	16-DIP (0.300', 7.62mm)	64-VFQFN Exposed Pad
Package	-	Tape & Reel (TR)	Tube	Tape & Reel (TR)
Tolerance	-	-	-	-
Base Product Number	-	DAC34H84	MAX500	ADS62P42
Series	-	-	-	-
Output Type	-	Current - Unbuffered	Voltage - Buffered	-
Supplier Device Package	-	196-NFBGA (12x12)	16-PDIP	64-VQFN (9x9)
Voltage - Input	-	-	-	-
Noise - 10Hz to 10kHz	-	-	-	-
Voltage - Output (Min/Fixed)	-	-	-	-
Current - Output	-	-	-	-
Mounting Type	-	Surface Mount	Through Hole	Surface Mount
Temperature Coefficient	-	-	-	-
Noise - 0.1Hz to 10Hz	-	-	-	-
Operating Temperature	-	-40°C ~ 85°C	0°C ~ 70°C	-40°C ~ 85°C
Reference Type	-	External, Internal	External	External, Internal
Current - Supply	-	-	-	-

REF3112AIDBZR Datasheet PDF

Download REF3112AIDBZR pdf datasheets and Texas Instruments documentation for REF3112AIDBZR - Texas Instruments.

HTML Datasheet: REF3112/20/25/30/33/40.pdf
PCN Assembly/Origin: REF3yyy 13/Nov/2019.pdf
PCN Design/Specification: Wire Chg 19/Mar/2016.pdf
