Home Products Integrated Circuits (ICs)Logic - Flip Flops~~SN74LVC1G175DBVR~~

Image may be representation.
See specifications for product details.

~~Favorite~~

EXPRESS OPTION

Payment method

SN74LVC1G175DBVR - Texas Instruments

Name: Texas Instruments SN74LVC1G175DBVR
Brand: Texas Instruments
SKU: SN74LVC1G175DBVR
Price: 0.034 USD
Availability: InStock
Rating: 5 (1 reviews)

Manufacturer Part Number: SN74LVC1G175DBVR

Manufacturer: Texas Instruments

Allelco Part Number: 32D-SN74LVC1G175DBVR

Warranty: 1 Year Allelco Warranty - Find out more

Parts Description: IC FF D-TYPE SNGL 1BIT SOT23-6

Package: SOT-23-6

Data sheet: 1.SN74LVC1G175DBV.pdf ...

HTML Datasheet
SN74LVC1G175.pdf

PCN Assembly/Origin
2.73KHz.pdf

PCN Design/Specification
Select Devices Add Cu Alt Wire Base Metal 17/Dec/2.pdf

RoHs Status: ROHS3 Compliant

~~Compare~~

Our certification

In stock: 394800

Unit Price: $0.064
Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity	Unit Price	Ext. Price
5+	$0.064	$0.32
50+	$0.052	$2.60
150+	$0.046	$6.90
500+	$0.042	$21.00
3000+	$0.036	$108.00
6000+	$0.034	$204.00

The above prices does not include taxes and freight rates, which will be calculated on the order pages.

EXPRESS OPTION

Payment method

Our certification

Specifications

SN74LVC1G175DBVR Tech Specifications
Texas Instruments - SN74LVC1G175DBVR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - SN74LVC1G175DBVR

Product Attribute	Attribute Value
Manufacturer	Texas Instruments
Voltage - Supply	1.65V ~ 5.5V
Type	D-Type
Trigger Type	Positive Edge
Supplier Device Package	SOT-23-6
Series	74LVC
Package / Case	SOT-23-6
Package	Tape & Reel (TR)
Output Type	Non-Inverted
Operating Temperature	-40°C ~ 125°C (TA)

Product Attribute	Attribute Value
Number of Elements	1
Number of Bits per Element	1
Mounting Type	Surface Mount
Max Propagation Delay @ V, Max CL	5ns @ 5V, 50pF
Input Capacitance	3 pF
Function	Reset
Current - Quiescent (Iq)	10 µA
Current - Output High, Low	32mA, 32mA
Clock Frequency	175 MHz
Base Product Number	74LVC1G175

Environmental & Export Classifications

ATTRIBUTE	DESCRIPTION
RoHs Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001

Parts Introduction

Manufacturer Part Number

SN74LVC1G175DBVR

Manufacturer

Texas Instruments

Introduction

High-performance logic device

Single D-type flip-flop with reset function

Product Features and Performance

Operates from 1.65V to 5.5V power supply

Propagation delay as low as 5ns

High-speed operation up to 175MHz

Low power consumption with quiescent current of 10μA

32mA output drive capability

Product Advantages

Compact SOT-23-6 package

Wide operating temperature range of -40°C to 125°C

ROHS3 compliant

Key Technical Parameters

Voltage supply: 1.65V to 5.5V

Quiescent current: 10μA

Output drive: 32mA

Propagation delay: 5ns @ 5V, 50pF

Clock frequency: Up to 175MHz

Quality and Safety Features

ROHS3 compliant

Reliable surface mount technology

Compatibility

Suitable for a wide range of digital logic applications

Application Areas

Digital electronics

Embedded systems

Instrumentation

Communication equipment

Product Lifecycle

Currently in production

Replacement or upgrade options available

Key Reasons to Choose This Product

High-speed performance with low power consumption

Compact and reliable surface mount package

Wide operating temperature range

ROHS3 compliance for environmental safety

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments SN74LVC1G175DBVR

Product Attribute
Part Number	SN74LVC1G175DBVT	SN74LVC1G175DCKR	SN74LVC1G175YZPR	SN74LVC1G175YEPR
Manufacturer	Texas Instruments	Texas Instruments	Texas Instruments	Texas Instruments
Output Type	-	Current - Unbuffered	Voltage - Buffered	-
Trigger Type	-	-	-	-
Series	-	-	-	-
Number of Bits per Element	-	-	-	-
Supplier Device Package	-	196-NFBGA (12x12)	16-PDIP	64-VQFN (9x9)
Type	-	-	-	-
Package / Case	-	196-LFBGA	16-DIP (0.300', 7.62mm)	64-VFQFN Exposed Pad
Number of Elements	-	-	-	-
Clock Frequency	-	-	-	-
Current - Quiescent (Iq)	-	-	-	-
Input Capacitance	-	-	-	-
Max Propagation Delay @ V, Max CL	-	-	-	-
Base Product Number	-	DAC34H84	MAX500	ADS62P42
Voltage - Supply	-	-	-	-
Operating Temperature	-	-40°C ~ 85°C	0°C ~ 70°C	-40°C ~ 85°C
Package	-	Tape & Reel (TR)	Tube	Tape & Reel (TR)
Current - Output High, Low	-	-	-	-
Function	-	-	-	-
Mounting Type	-	Surface Mount	Through Hole	Surface Mount

SN74LVC1G175DBVR Datasheet PDF

Download SN74LVC1G175DBVR pdf datasheets and Texas Instruments documentation for SN74LVC1G175DBVR - Texas Instruments.

HTML Datasheet: SN74LVC1G175.pdf
PCN Assembly/Origin: 2.73KHz.pdf
PCN Design/Specification: Select Devices Add Cu Alt Wire Base Metal 17/Dec/2.pdf
