TAS5782MDCAR Image
TAS5782MDCAR Image - 1TAS5782MDCAR Image - 2
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

TAS5782MDCAR - Texas Instruments

Manufacturer Part Number
TAS5782MDCAR
Manufacturer
Texas Instruments
Allelco Part Number
32D-TAS5782MDCAR
Warranty
1 Year Allelco Warranty - Find out more
Stock Status:
10,669 pcs available, New & Original
Parts Description
IC AMP CLASS D STEREO 48HTSSOP
Package
48-HTSSOP
Data sheet
TAS5782MDCAR.pdf

PCN Design/Specification

Design 22/Feb/2022.pdf
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 10669
  • Unit Price: $1.057
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $1.057 $1.06
10+ $0.969 $9.69
30+ $0.913 $27.39
100+ $0.779 $77.90
500+ $0.754 $377.00
1000+ $0.743 $743.00
The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Specifications

TAS5782MDCAR Tech Specifications
Texas Instruments - TAS5782MDCAR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TAS5782MDCAR

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Supply 4.5V ~ 26.4V
Type Class D
Supplier Device Package 48-HTSSOP
Series -
Package / Case 48-TFSOP (0.240", 6.10mm Width) Exposed Pad
Package Tape & Reel (TR)
Product Attribute Attribute Value
Output Type 2-Channel (Stereo)
Operating Temperature -25°C ~ 85°C (TA)
Mounting Type Surface Mount
Max Output Power x Channels @ Load -
Features Differential Inputs, Short-Circuit and Thermal Protection
Base Product Number TAS5782

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99

Parts Introduction

TAS5782MDCAR Image
TAS5782MDCAR (1)

Manufacturer Part Number

TAS5782MDCAR

Manufacturer

Texas Instruments

Introduction

Integrated circuit (IC) for audio amplification

Part of the TAS5782 series of audio amplifier ICs

Product Features and Performance

2-channel (stereo) Class D audio amplifier

Differential inputs

Short-circuit and thermal protection

Wide supply voltage range: 4.5V to 26.4V

Operates in the temperature range of -25°C to 85°C

Product Advantages

Efficient Class D amplification technology

Robust protection features

Wide operating voltage and temperature range

TAS5782MDCAR Image
TAS5782MDCAR (2)

Key Technical Parameters

Output Type: 2-Channel (Stereo)

Mounting Type: Surface Mount

Package: 48-HTSSOP

Quality and Safety Features

RoHS3 compliant

Short-circuit and thermal protection

Compatibility

Compatible with a variety of audio systems and applications

Application Areas

Suitable for use in various audio amplification applications, such as:

- Portable audio devices

- Home audio systems

- Professional sound equipment

Product Lifecycle

Currently available, no indication of discontinuation

Replacement or upgrade options may be available from the manufacturer

Several Key Reasons to Choose This Product

Efficient Class D amplification for high-quality audio output

Wide operating voltage and temperature range for versatile application

Robust protection features for reliable and safe operation

Compatibility with a variety of audio systems and applications

Frequently Asked Questions(FAQ)

What are the key thermal and protection features of the TAS5782MDCAR that influence reliability in high-power Class D amplifier designs?
The TAS5782MDCAR incorporates integrated short-circuit and thermal protection mechanisms designed to prevent device damage under fault conditions. These protections respond to overcurrent events and junction temperature excursions, automatically reducing output or shutting down the amplifier when thresholds are exceeded. This behavior is critical in compact designs where airflow is limited and power dissipation can be significant. Engineers should account for these response characteristics when designing fault recovery sequences, as abrupt shutdowns may affect audio continuity. Thermal derating curves in the datasheet indicate a gradual reduction in maximum output power as ambient temperature rises from -25°C to 85°C, with full performance typically available only below 70°C.
How does the supply voltage range of the TAS5782MDCAR impact system design in automotive or industrial applications, and what considerations arise at the lower end of this range?
With a supply voltage range spanning 4.5V to 26.4V, the TAS5782MDCAR supports diverse power delivery architectures, including battery-powered systems, automotive 12V rails, and PoE-like configurations. At the low end near 4.5V, headroom for load transients and output swing becomes constrained, potentially limiting maximum undistorted output power. Designers must ensure that the minimum supply remains above this threshold during all operating modes, especially when accounting for voltage drops due to cable resistance or regulator inefficiency. Additionally, switching noise from adjacent power stages should not push the input below 4.5V to avoid undefined operation or latch-up.
When comparing the TAS5782MDCAR to other stereo Class D amplifiers like the TAS5754M or TPA3122D2, what architectural differences might justify choosing the TAS5782MDCAR despite similar channel counts?
Unlike simpler bridge-tied load (BTL) topologies found in amplifiers such as the TPA3122D2, the TAS5782MDCAR employs a dual mono, single-ended output configuration per channel, offering better crosstalk isolation and easier interfacing with differential microphones or balanced line inputs. Its support for differential inputs enables improved rejection of common-mode noise, which is advantageous in noisy environments. Compared to the TAS5754M, the TAS5782MDCAR offers enhanced integration with Texas Instruments’ audio processing ecosystem, including tighter synchronization with digital audio interfaces and more sophisticated protection logic. This makes it preferable in systems requiring robust performance under variable loads and demanding reliability standards.
What mounting considerations apply to the 48-HTSSOP package of the TAS5782MDCAR, and how does its Moisture Sensitivity Level affect manufacturing workflow?
The TAS5782MDCAR is housed in a 48-pin HTSSOP package measuring 6.10mm in width and 0.240" pitch, requiring standard surface-mount assembly processes compatible with most PCB layouts. As an MSL 3 component with a floor life of 168 hours at 30°C/60% RH, the device must be stored in dry packaging after baking and used within this timeframe if exposed to ambient moisture. Manufacturers must implement humidity monitoring and controlled storage to prevent popcorning during reflow. The thermal pad on the underside aids heat sinking but requires proper soldering techniques—typically using a solder paste stencil and reflow profile compliant with JEDEC J-STD-020—to ensure reliable thermal and electrical connection.
In what scenarios would the operating temperature range of -25°C to 85°C make the TAS5782MDCAR suitable for industrial versus consumer-grade equipment?
The extended operating range down to -25°C allows the TAS5782MDCAR to function reliably in cold-start environments such as outdoor signage, HVAC controls, or automotive infotainment systems where temperatures may drop significantly. The upper limit of 85°C aligns with typical industrial enclosure conditions but may require heatsinking or airflow management in sealed enclosures with poor thermal conductivity. Unlike consumer electronics rated for 0°C to 70°C, this amplifier can maintain performance in harsher climates without derating beyond specified limits—provided PCB layout minimizes parasitic inductance and capacitance that could exacerbate switching losses.
How does the TAS5782MDCAR handle electromagnetic compatibility (EMC), and what layout practices reduce radiated emissions in Class D amplifier circuits?
While the datasheet does not specify radiated emission limits, the TAS5782MDCAR's internal dead-time control and spread-spectrum modulation help reduce high-frequency harmonics associated with traditional Class D switching. However, external factors such as trace routing, bypass capacitor placement, and output filter design dominate EMC behavior. To minimize emissions, designers should keep high-current paths short, use star grounding near the IC, and place decoupling capacitors as close as possible to VDD pins. A properly tuned LC output filter reduces conducted emissions into speakers while maintaining audio fidelity—critical when meeting EN 55032 or CISPR 32 standards in broadcast or professional audio gear.
Can the TAS5782MDCAR operate directly from a single Li-ion battery, and what modifications might be needed for stable performance?
Yes, the TAS5782MDCAR can operate from a single-cell Li-ion battery providing approximately 3.0V to 4.2V, falling within its 4.5V minimum supply requirement only when fully charged. However, during discharge, battery voltage may dip below 4.5V, causing instability or shutdown. To address this, a boost converter or low-dropout regulator capable of maintaining at least 4.5V is recommended. Alternatively, using two series cells increases headroom but raises cost and size. In either case, transient response and efficiency trade-offs must be evaluated, particularly during sudden volume changes where high peak currents stress the power stage.
What role does the base product number TAS5782 play in selecting variants of the TAS5782MDCAR, and how do package or pin-out differences affect compatibility?
The base product number TAS5782 encompasses multiple package options (e.g., HTSSOP, QFN) and minor feature variations across regions or generations. The TAS5782MDCAR specifically denotes the 48-pin HTSSOP version with commercial automotive-grade marking and RoHS3 compliance. Pin-out compatibility between packages depends on functional mapping; however, physical form factor differences necessitate separate PCB footprints. Designers should verify that critical signals like PWM inputs, enable pins, and thermal reporting remain aligned when substituting variants. Cross-referencing TI’s product folder ensures correct signal assignments and avoids layout mismatches during migration between production lines.
