Manufacturer Part Number
TPIC6C596N
Manufacturer
Texas Instruments
Introduction
The TPIC6C596N is a high-performance, 8-bit serial-to-parallel shift register with open-drain outputs, designed for use in a variety of industrial and consumer applications.
Product Features and Performance
8-bit serial-to-parallel shift register with open-drain outputs
Wide operating voltage range of 4.5V to 5.5V
High-speed operation up to 25 MHz
Low operating current of 10 mA (typical)
Supports serial data input, serial clock, and output latch
Operates over a wide temperature range of -40°C to 125°C
Product Advantages
Versatile and flexible design for various applications
High-speed operation for efficient data transfer
Low power consumption for energy-efficient systems
Wide operating temperature range for reliable performance in diverse environments
Key Technical Parameters
Operating Voltage: 4.5V to 5.5V
Operating Temperature: -40°C to 125°C
Maximum Clock Frequency: 25 MHz
Supply Current: 10 mA (typical)
Number of Bits per Element: 8
Number of Elements: 1
Quality and Safety Features
RoHS3 compliant for environmental responsibility
16-PDIP package for through-hole mounting
Compatibility
The TPIC6C596N is compatible with a wide range of industrial and consumer electronic devices that require serial-to-parallel data conversion with open-drain outputs.
Application Areas
Industrial control systems
Consumer electronics
Automotive electronics
Lighting control systems
Display drivers
Data acquisition systems
Product Lifecycle
The TPIC6C596N is an active product, and Texas Instruments continues to manufacture and support it. Replacement or upgrade options may be available as technology evolves.
Several Key Reasons to Choose This Product
Versatile and flexible design for a wide range of applications
High-speed operation up to 25 MHz for efficient data transfer
Low power consumption for energy-efficient systems
Wide operating temperature range for reliable performance in diverse environments
RoHS3 compliance for environmental responsibility
Through-hole mounting option for easy integration into existing designs
