HomeProductsIntegrated Circuits (ICs)PMIC - Power Distribution Switches, Load DriversTPS2001CDGN
TPS2001CDGN Image
TPS2001CDGN Image - 1TPS2001CDGN Image - 2TPS2001CDGN Image - 3
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

TPS2001CDGN - Texas Instruments

Manufacturer Part Number
TPS2001CDGN
Manufacturer
Texas Instruments
Allelco Part Number
32D-TPS2001CDGN
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
IC PWR SWITCH N-CHAN 1:1 8MSOP
Package
8-HVSSOP
Data sheet
1.TPS2001CDGN.pdf ...

PCN Assembly/Origin

2.73KHz.pdf

HTML Datasheet

TPS20xxC.pdf
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 58830
  • Unit Price: $1.185
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $1.185 $1.19
10+ $1.029 $10.29
30+ $0.931 $27.93
100+ $0.831 $83.10
500+ $0.785 $392.50
1000+ $0.766 $766.00
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

TPS2001CDGN Tech Specifications
Texas Instruments - TPS2001CDGN technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TPS2001CDGN

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Supply (Vcc/Vdd) Not Required
Voltage - Load 4.5V ~ 5.5V
Switch Type USB Switch
Supplier Device Package 8-HVSSOP
Series -
Rds On (Typ) 72mOhm
Ratio - Input:Output 1:1
Package / Case 8-TSSOP, 8-MSOP (0.118', 3.00mm Width) Exposed Pad
Package Tube
Output Type N-Channel
Product Attribute Attribute Value
Output Configuration High Side
Operating Temperature -40°C ~ 125°C (TJ)
Number of Outputs 1
Mounting Type Surface Mount
Interface On/Off
Input Type Non-Inverting
Features Status Flag
Fault Protection Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
Current - Output (Max) 2A
Base Product Number TPS2001

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

Parts Introduction

Manufacturer Part Number

TPS2001CDGN

Manufacturer

Texas Instruments

Introduction

The TPS2001CDGN is a specialized power management integrated circuit (PMIC) designed by Texas Instruments for power distribution and load driving, specifically tailored for USB switching applications.

Product Features and Performance

High Side N-Channel Output configuration for efficient power switching

Supports 4.5V to 5.5V load voltage, accommodating standard USB power requirements

Maximum output current of 2A, suitable for high-demand USB devices

72mOhm typical Rds On, ensuring low on-resistance for efficient operation

Non-Inverting input for straightforward signal processing

Features output discharge function for enhanced power-off protection

Integrated fault protection includes fixed current limiting, over-temperature protection, reverse current prevention, and under-voltage lockout (UVLO)

Operates reliably within a temperature range of -40°C to 85°C

Product Advantages

High integration level for simplified circuit design and reduced board space

Specifically designed for USB power distribution, offering high compatibility and reliability

Robust fault protection features safeguard against common power-related faults

Key Technical Parameters

Number of Outputs: 1

Voltage Load: 4.5V ~ 5.5V

Current Output (Max): 2A

Rds On (Typ): 72mOhm

Operating Temperature: -40°C ~ 85°C

Packaging: 8-HVSSOP

Quality and Safety Features

Features comprehensive fault protection for enhanced safety and reliability

Robust design ensures reliable operation in diverse environmental conditions

Compatibility

Tailored for USB switch applications, ensuring compatibility with a wide range of USB-powered devices

Application Areas

USB hubs and ports

Power distribution for consumer electronics

Load driving in portable and battery-powered devices

Product Lifecycle

Currently in Active status, not nearing discontinuation

Continued support and availability are expected from Texas Instruments

Several Key Reasons to Choose This Product

Tailored design for USB power applications ensures optimal performance and compatibility

Robust fault protection features enhance device safety and reliability

Efficient power switching capabilities with a low on-resistance

Support from a reputable manufacturer in Texas Instruments with a commitment to quality and reliability

Suitable for a wide range of applications from consumer electronics to portable devices

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments TPS2001CDGN

Product Attribute TPS2001CDGNR TPS2001CDGK TPS2000CDGNR TPS2001CDGKR
Part Number TPS2001CDGNR TPS2001CDGK TPS2000CDGNR TPS2001CDGKR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Features - - - Simultaneous Sampling
Input Type - - - Differential
Rds On (Typ) - - - -
Number of Outputs - - - -
Base Product Number - DAC34H84 MAX500 ADS62P42
Package - Tape & Reel (TR) Tube Tape & Reel (TR)
Series - - - -
Interface - - - -
Output Configuration - - - -
Package / Case - 196-LFBGA 16-DIP (0.300', 7.62mm) 64-VFQFN Exposed Pad
Ratio - Input:Output - - - -
Mounting Type - Surface Mount Through Hole Surface Mount
Voltage - Supply (Vcc/Vdd) - - - -
Fault Protection - - - -
Operating Temperature - -40°C ~ 85°C 0°C ~ 70°C -40°C ~ 85°C
Switch Type - - - -
Output Type - Current - Unbuffered Voltage - Buffered -
Current - Output (Max) - - - -
Voltage - Load - - - -
Supplier Device Package - 196-NFBGA (12x12) 16-PDIP 64-VQFN (9x9)

TPS2001CDGN Datasheet PDF

Download TPS2001CDGN pdf datasheets and Texas Instruments documentation for TPS2001CDGN - Texas Instruments.

PCN Assembly/Origin
