TPS2553DRVT Image
TPS2553DRVT Image - 1TPS2553DRVT Image - 2
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

TPS2553DRVT - Texas Instruments

Manufacturer Part Number
TPS2553DRVT
Manufacturer
Texas Instruments
Allelco Part Number
32D-TPS2553DRVT
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
IC PWR SWITCH N-CHAN 1:1 6WSON
Package
6-WSON (2x2)
Data sheet
1.TPS2553DRVT.pdf ...

HTML Datasheet

TPS2552/53(-1).pdf

PCN Design/Specification

Cylindrical Battery Holders.pdf
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 54690
  • Unit Price: $0.359
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $0.359 $0.36
10+ $0.299 $2.99
30+ $0.269 $8.07
250+ $0.232 $58.00
500+ $0.215 $107.50
1000+ $0.205 $205.00
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

TPS2553DRVT Tech Specifications
Texas Instruments - TPS2553DRVT technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TPS2553DRVT

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Supply (Vcc/Vdd) Not Required
Voltage - Load 2.5V ~ 6.5V
Switch Type General Purpose
Supplier Device Package 6-WSON (2x2)
Series -
Rds On (Typ) 100mOhm
Ratio - Input:Output 1:1
Package / Case 6-WDFN Exposed Pad
Package Tape & Reel (TR)
Output Type N-Channel
Product Attribute Attribute Value
Output Configuration High Side
Operating Temperature -40°C ~ 150°C (TJ)
Number of Outputs 1
Mounting Type Surface Mount
Interface On/Off
Input Type Non-Inverting
Features Slew Rate Controlled, Status Flag
Fault Protection Current Limiting (Adjustable), Over Temperature, UVLO
Current - Output (Max) 1.5A
Base Product Number TPS2553

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

Parts Introduction

Manufacturer Part Number

TPS2553DRVT

Manufacturer

Texas Instruments

Introduction

The TPS2553DRVT is a power management integrated circuit designed for power distribution and load driving.

Product Features and Performance

Single output, general purpose switch

High Side output configuration with N-Channel output type

Features slew rate control and status flag

Supports a wide operating voltage load from 2.5V to 6.5V

Capable of delivering up to 1.5A current output

Rds On resistance typically at 100mOhm

Integrates fault protection including adjustable current limiting, over temperature protection, and under voltage lockout (UVLO)

Operates effectively in a temperature range from -40°C to 150°C

Product Advantages

Enhanced safety with multiple built-in fault protection measures

Slew rate controlled to prevent inrush current damage

Status flag allows for real-time monitoring

Operates over a broad voltage and temperature range, suitable for diverse applications

Key Technical Parameters

Voltage Load: 2.5V ~ 6.5V

Current Output (Max): 1.5A

Rds On (Typ): 100mOhm

Operating Temperature: -40°C ~ 150°C (TJ)

Quality and Safety Features

Current Limiting (Adjustable)

Over Temperature Protection

Under Voltage Lockout (UVLO)

Compatibility

Surface mount 6-WSON (2x2) package compatible with standard mounting processes

Application Areas

Power distribution systems

Load driving in electronic devices

Product Lifecycle

Status: Active

No current plans for discontinuation, ensuring long-term availability and support

Several Key Reasons to Choose This Product

Robust fault protection features ensuring device and circuit safety

Efficient power handling capability with controlled slew rate and minimal heat generation

Flexible and broad operating conditions make it adaptable to multiple applications

Real-time monitoring capability through the status flag feature

Reliable performance from a leading manufacturer with excellent support and no foreseen discontinuation.
