Manufacturer Part Number
TPS3701DDCR
Manufacturer
Texas Instruments
Introduction
The TPS3701DDCR is a high-precision window comparator from Texas Instruments, designed for voltage monitoring applications.
Product Features and Performance
Window comparator type
Single element configuration
Open-drain output type
Operating power supply range from 1.8V to 36V
Ultra-low quiescent current of 11µA
Fast propagation delay of 28.1µs
Voltage hysteresis set at 5.5mV
Supports a wide operating temperature range from -40°C to 125°C
Product Advantages
Long-term reliability with a wide voltage supply range.
Highly precise for critical monitoring applications.
Suitable for harsh operating environments due to its broad temperature range.
Key Technical Parameters
Supply Voltage: 1.8V ~ 36V
Quiescent Current (Max): 11µA
Propagation Delay (Max): 28.1µs
Hysteresis: 5.5mV
Operating Temperature: -40°C ~ 125°C
Quality and Safety Features
Robust design ensuring stable performance over various environmental conditions.
Precision components used to minimize errors.
Compatibility
Compatible with various circuits due to its wide voltage range and SOT-23-6 package.
Application Areas
Industrial automation
Critical system voltage monitoring
Portable and battery-powered equipment
Over-voltage and under-voltage detection
Product Lifecycle
Product status: Active
Not nearing discontinuation
Standard lifecycle with replacements and upgrades available
Several Key Reasons to Choose This Product
Wide voltage range accommodating various power supplies.
Ultra-low power consumption ideal for battery-operated devices.
Fast response time suitable for rapid system response applications.
High precision ensures system reliability and safety.
Durable design suitable for extreme temperatures and rigorous conditions.
