Manufacturer Part Number
TPS3825-33DBVR
Manufacturer
Texas Instruments
Introduction
The TPS3825-33DBVR is a voltage monitor device designed for Power Management. It serves to ensure system stability by monitoring power supply status and initiating a reset if necessary.
Product Features and Performance
Monitors single voltage
Voltage threshold set at 2.93V
Provides active high reset signal
Reset timeout duration of 120ms minimum ensures proper system recovery
Operates over a temperature range of -40°C to 85°C
Designed for surface mount technology for easy PCB integration
Product Advantages
High reliability in monitoring system power supply status
Prevention of system failures through timely reset
Seamless integration into system design thanks to SOT-23-5 packaging
Low power consumption enhances overall system efficiency
Key Technical Parameters
Voltage monitored: 1
Voltage threshold: 2.93V
Output type: Push-Pull, Totem Pole
Reset type: Active High
Reset Timeout: 120ms Minimum
Operating Temperature: -40°C to 85°C
Package: SC-74A, SOT-753 (SOT-23-5)
Quality and Safety Features
Robust construction for long-term performance
Meets industry standards for safety and quality
Compatibility
Compatible with a wide range of power management systems requiring voltage monitoring
Application Areas
Embedded systems
Microcontroller units (MCUs)
Networking equipment
Consumer electronics
Industrial controls
Product Lifecycle
Active status; not nearing discontinuation
Replacement or upgrade options available for future-proofing applications
Several Key Reasons to Choose This Product
Accurate voltage threshold for reliable monitoring
Extended operating temperature range suitable for various environments
Minimal reset timeout ensures quick system response
Ease of integration into existing designs with surface mount packaging
Proven track record of performance from Texas Instruments
Supports a broad range of applications, from consumer electronics to industrial controls
