Manufacturer Part Number
TPS76301DBVR
Manufacturer
Texas Instruments
Introduction
The TPS76301DBVR from Texas Instruments is a linear low-dropout voltage regulator suitable for a variety of electronic applications.
Product Features and Performance
Adjustable output voltage from 1.5V to 6.5V for a range of power requirements
Linear regulator offers low dropout performance for improved efficiency
A single regulator design simplifies circuit complexity
Up to 150mA current output to power a range of devices
Ultra-low quiescent current of 100 µA ideal for battery-powered applications
High PSRR of 60dB at 1kHz helps to minimize output noise
Control features include an Enable pin for on/off control
Integration of protection features enhances device safety
Product Advantages
Designed for high-performance power management
Versatile adjustable output to meet different voltage requirements
High power supply rejection ratio ensures stable operation
Protection features safeguard against common electrical issues
Low quiescent current extends battery life in portable devices
Key Technical Parameters
Voltage - Input (Max): 10V
Voltage - Output (Min/Fixed): 1.5V
Voltage - Output (Max): 6.5V
Current - Output: 150mA
Current - Quiescent (Iq): 100 µA
Current - Supply (Max): 140 µA
PSRR: 60dB (1kHz)
Quality and Safety Features
Over Current Protection
Over Temperature Protection
Reverse Polarity Protection
Compatibility
Compatible with surface mount technology for PCB assembly
Mounting Type: SC-74A, SOT-753
Supplier Device Package: SOT-23-5
Application Areas
Consumer Electronics
Telecommunication Systems
Battery-Powered Devices
Portable Instrumentation
Product Lifecycle
Product Status: Active
Not reported as nearing discontinuation, replacement or upgrade options have not been specified
Several Key Reasons to Choose This Product
Texas Instruments' reputation for producing high-quality, reliable components
Flexible voltage output range catering to a variety of design needs
High PSRR for stable voltage supply despiite variable input voltage
Integrated safety features to protect the end application
Low quiescent current ideal for energy-sensitive designs
Broad operating temperature range suitable for diverse environmental conditions
