HomeProductsIntegrated Circuits (ICs)PMIC - Voltage Regulators - LinearTPS7A0533PDBZR
TPS7A0533PDBZR Image
TPS7A0533PDBZR Image - 1TPS7A0533PDBZR Image - 2
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

TPS7A0533PDBZR - Texas Instruments

Manufacturer Part Number
TPS7A0533PDBZR
Manufacturer
Texas Instruments
Allelco Part Number
32D-TPS7A0533PDBZR
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
IC REG LINEAR 3.3V 200MA SOT23-3
Package
SOT-23-3
Data sheet
1.TPS7A0533PDBZR.pdf ...
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 150080
  • Unit Price: $0.079
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
5+ $0.079 $0.40
50+ $0.077 $3.85
150+ $0.076 $11.40
500+ $0.075 $37.50
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

TPS7A0533PDBZR Tech Specifications
Texas Instruments - TPS7A0533PDBZR technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - TPS7A0533PDBZR

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage Dropout (Max) 0.24V @ 200mA
Voltage - Output (Min/Fixed) 3.3V
Voltage - Output (Max) -
Voltage - Input (Max) 5.5V
Supplier Device Package SOT-23-3
Series -
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Package / Case TO-236-3, SC-59, SOT-23-3
Package Tape & Reel (TR)
Product Attribute Attribute Value
PSRR 40dB (1kHz ~ 1MHz)
Output Type Fixed
Output Configuration Positive
Operating Temperature -40°C ~ 125°C (TJ)
Number of Regulators 1
Mounting Type Surface Mount
Current - Quiescent (Iq) 3 µA
Current - Output 200mA
Control Features Enable
Base Product Number TPS7A0533

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

Parts Introduction

Manufacturer Part Number

TPS7A0533PDBZR

Manufacturer

Texas Instruments

Introduction

Low dropout voltage regulator

Product Features and Performance

Output Configuration: Positive

Output Type: Fixed

Current - Output: 200mA

Low Dropout: 0.24V @ 200mA

Low Quiescent Current: 3 µA

High PSRR: 40dB (1kHz ~ 1MHz)

Temperature Range: -40°C ~ 125°C

Product Advantages

High-efficiency power conversion

Stable output with fixed 3.3V

Low-power operation suitable for battery-powered devices

Robust thermal performance

Key Technical Parameters

Number of Regulators: 1

Voltage - Input (Max): 5.5V

Voltage - Output (Min/Fixed): 3.3V

Voltage Dropout (Max): 0.24V

PSRR: 40dB

Quality and Safety Features

Protection against overcurrent conditions

Overtemperature protection

Under Voltage Lockout (UVLO)

Compatibility

Compatible with surfaces mount technology

Fits in a TO-236-3, SC-59, SOT-23-3 package

Application Areas

Portable electronics

Battery-powered devices

Consumer electronics

Power supply modules

Product Lifecycle

Status: Active

No near discontinuation, replacements, or upgrades indicated

Several Key Reasons to Choose This Product

Efficient power management for portable applications

Long-term stability through wide temperature variations

Minimal power loss with high PSRR

Easy integration into circuit designs due to SOT-23-3 package

Reliable operation with built-in protection features

Parts with Similar Specifications

The three parts on the right have similar specifications to Texas Instruments TPS7A0533PDBZR

Product Attribute TPS7A0533PDBVR TPS7A0533PDBZT TPS7A0531PDBVR TPS7A0533PDQNR
Part Number TPS7A0533PDBVR TPS7A0533PDBZT TPS7A0531PDBVR TPS7A0533PDQNR
Manufacturer Texas Instruments Texas Instruments Texas Instruments Texas Instruments
Current - Output - - - -
PSRR - - - -
Output Configuration - - - -
Supplier Device Package - 196-NFBGA (12x12) 16-PDIP 64-VQFN (9x9)
Output Type - Current - Unbuffered Voltage - Buffered -
Package / Case - 196-LFBGA 16-DIP (0.300', 7.62mm) 64-VFQFN Exposed Pad
Voltage - Output (Min/Fixed) - - - -
Number of Regulators - - - -
Voltage - Input (Max) - - - -
Control Features - - - -
Protection Features - - - -
Current - Quiescent (Iq) - - - -
Voltage - Output (Max) - - - -
Package - Tape & Reel (TR) Tube Tape & Reel (TR)
Voltage Dropout (Max) - - - -
Operating Temperature - -40°C ~ 85°C 0°C ~ 70°C -40°C ~ 85°C
Base Product Number - DAC34H84 MAX500 ADS62P42
Mounting Type - Surface Mount Through Hole Surface Mount
Series - - - -
