Specifications
VXB2-1B4-10M0000000TR Tech Specifications
Microchip Technology - VXB2-1B4-10M0000000TR technical specifications, attributes, parameters and parts with similar specifications to Microchip Technology - VXB2-1B4-10M0000000TR
| Product Attribute |
Attribute Value
| |
| Manufacturer |
Microchip Technology |
|
| Type |
MHz Crystal |
|
| Size / Dimension |
0.449" L x 0.191" W (11.40mm x 4.85mm) |
|
| Series |
VXB2 |
|
| Ratings |
- |
|
| Package / Case |
HC-49/US |
|
| Package |
Tape & Reel (TR) |
|
| Operating Temperature |
-20°C ~ 70°C |
|
| Product Attribute |
Attribute Value
| |
| Operating Mode |
Fundamental |
|
| Mounting Type |
Surface Mount |
|
| Load Capacitance |
18pF |
|
| Height - Seated (Max) |
0.173" (4.40mm) |
|
| Frequency Tolerance |
±20ppm |
|
| Frequency Stability |
±50ppm |
|
| Frequency |
10 MHz |
|
| ESR (Equivalent Series Resistance) |
40 Ohms |
|
