HomeProductsDiscrete Semiconductor ProductsTransistors - FETs, MOSFETs - SingleSTW12N120K5
STW12N120K5 Image
STW12N120K5 Image - 1STW12N120K5 Image - 2STW12N120K5 Image - 3
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

STW12N120K5 - STMicroelectronics

Manufacturer Part Number
STW12N120K5
Manufacturer
STMicroelectronics
Allelco Part Number
32D-STW12N120K5
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
MOSFET N-CH 1200V 12A TO247
Package
TO-247-3
Data sheet
1.STW12N120K5.pdf ...
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 6442
  • Unit Price: $2.14
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $2.14 $2.14
10+ $1.849 $18.49
30+ $1.676 $50.28
100+ $1.501 $150.10
500+ $1.421 $710.50
1000+ $1.384 $1,384.00
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

STW12N120K5 Tech Specifications
STMicroelectronics - STW12N120K5 technical specifications, attributes, parameters and parts with similar specifications to STMicroelectronics - STW12N120K5

Product Attribute Attribute Value
Manufacturer STMicroelectronics
Vgs(th) (Max) @ Id 5V @ 100µA
Vgs (Max) ±30V
Technology MOSFET (Metal Oxide)
Supplier Device Package TO-247-3
Series MDmesh™ K5
Rds On (Max) @ Id, Vgs 690mOhm @ 6A, 10V
Power Dissipation (Max) 250W (Tc)
Package / Case TO-247-3
Package Tube
Product Attribute Attribute Value
Operating Temperature -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Input Capacitance (Ciss) (Max) @ Vds 1370 pF @ 100 V
Gate Charge (Qg) (Max) @ Vgs 44.2 nC @ 10 V
FET Type N-Channel
FET Feature -
Drive Voltage (Max Rds On, Min Rds On) 10V
Drain to Source Voltage (Vdss) 1200 V
Current - Continuous Drain (Id) @ 25°C 12A (Tc)
Base Product Number STW12

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99

Parts Introduction

Manufacturer Part Number

STW12N120K5

Manufacturer

STMicroelectronics

Introduction

High-performance N-Channel power MOSFET in TO-247-3 package

Product Features and Performance

Optimized for high-efficiency power conversion

Low on-resistance for low conduction losses

Fast switching for high-frequency operation

High voltage handling capability up to 1200V

Product Advantages

Excellent efficiency

Reliable and durable design

Suitable for a wide range of power applications

Key Technical Parameters

Drain to Source Voltage (Vdss): 1200V

Maximum Vgs: ±30V

On-Resistance (Rds(on)): 690mΩ @ 6A, 10V

Continuous Drain Current (Id): 12A @ 25°C (Tc)

Input Capacitance (Ciss): 1370pF @ 100V

Power Dissipation (Tc): 250W

Quality and Safety Features

ROHS3 compliant

Rigorous quality control and testing

Compatibility

Through-hole mounting in TO-247-3 package

Application Areas

High-efficiency power conversion

Switched-mode power supplies

Motor drives

Uninterruptible power supplies (UPS)

Induction heating

Welding equipment

Product Lifecycle

Currently in active production

No plans for discontinuation

Replacement or upgrade options available

Key Reasons to Choose This Product

Excellent efficiency and low power losses

High voltage and current handling capability

Reliable and durable design for long-term use

Suitable for a wide range of power conversion applications

Compatibility with common industry standards and packages

Parts with Similar Specifications

The three parts on the right have similar specifications to STMicroelectronics STW12N120K5

Product Attribute STW12N150K5 STW12N170K5 STW120NF10 STW12NK60Z
Part Number STW12N150K5 STW12N170K5 STW120NF10 STW12NK60Z
Manufacturer STMicroelectronics STMicroelectronics STMicroelectronics STMicroelectronics
Operating Temperature - -40°C ~ 85°C 0°C ~ 70°C -40°C ~ 85°C
Input Capacitance (Ciss) (Max) @ Vds - - - -
Technology - - - -
Package - Tape & Reel (TR) Tube Tape & Reel (TR)
Rds On (Max) @ Id, Vgs - - - -
Package / Case - 196-LFBGA 16-DIP (0.300', 7.62mm) 64-VFQFN Exposed Pad
FET Type - - - -
Series - - - -
Vgs (Max) - - - -
Drive Voltage (Max Rds On, Min Rds On) - - - -
FET Feature - - - -
Drain to Source Voltage (Vdss) - - - -
Vgs(th) (Max) @ Id - - - -
Supplier Device Package - 196-NFBGA (12x12) 16-PDIP 64-VQFN (9x9)
Base Product Number - DAC34H84 MAX500 ADS62P42
Power Dissipation (Max) - - - -
Current - Continuous Drain (Id) @ 25°C - - - -
Mounting Type - Surface Mount Through Hole Surface Mount
Gate Charge (Qg) (Max) @ Vgs - - - -
