HomeProductsDiscrete Semiconductor ProductsDiodes - Bridge RectifiersUG6KB80
UG6KB80 Image
UG6KB80 Image - 1
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

UG6KB80 - SMC Diode Solutions

Manufacturer Part Number
UG6KB80
Manufacturer
Sangdest Microelectronics / Nanjing (SMC Diode Solutions)
Allelco Part Number
98D-UG6KB80
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
BRIDGE RECT 1PHASE 800V 6A D3K
Package
D3K
Data sheet
1.UG6KB80.pdf ...

HTML Datasheet

UG6KB05 - UG6KB100.pdf

Environmental Information

SMC Diodes REACH 205.pdf SMC Diodes RoHS.pdf
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 34351
  • Unit Price: $0.253
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $0.253 $0.25
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

UG6KB80 Tech Specifications
SMC Diode Solutions - UG6KB80 technical specifications, attributes, parameters and parts with similar specifications to SMC Diode Solutions - UG6KB80

Product Attribute Attribute Value
Manufacturer Sangdest Microelectronics / Nanjing (SMC Diode Solutions)
Voltage - Peak Reverse (Max) 800 V
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 6 A
Technology Standard
Supplier Device Package D3K
Series -
Package / Case 4-ESIP
Product Attribute Attribute Value
Package Tube
Operating Temperature -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Diode Type Single Phase
Current - Reverse Leakage @ Vr 5 µA @ 800 V
Current - Average Rectified (Io) 6 A
Base Product Number UG6KB80

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080

Parts with Similar Specifications

The three parts on the right have similar specifications to SMC Diode Solutions UG6KB80

Product Attribute UG6KB80 BA1-B2-24-610-121-C
Part Number UG6KB80 BA1-B2-24-610-121-C
Manufacturer SMC Diode Solutions Carling Technologies
Package Tube Bulk
Package / Case 4-ESIP -
Series - B
Supplier Device Package D3K -
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 6 A -
Mounting Type Through Hole Panel Mount
Current - Average Rectified (Io) 6 A -
Current - Reverse Leakage @ Vr 5 µA @ 800 V -
Base Product Number UG6KB80 -
Voltage - Peak Reverse (Max) 800 V -
Diode Type Single Phase -
Operating Temperature -55°C ~ 150°C (TJ) -
Technology Standard -

UG6KB80 Datasheet PDF

Download UG6KB80 pdf datasheets and SMC Diode Solutions documentation for UG6KB80 - SMC Diode Solutions.

HTML Datasheet
UG6KB05 - UG6KB100.pdf
Environmental Information
SMC Diodes REACH 205.pdf SMC Diodes RoHS.pdf
