Specifications
TP65H015G5WS Tech Specifications
Transphorm - TP65H015G5WS technical specifications, attributes, parameters and parts with similar specifications to Transphorm - TP65H015G5WS
| Product Attribute |
Attribute Value
| |
| Manufacturer |
Transphorm |
|
| Vgs(th) (Max) @ Id |
4.8V @ 2mA |
|
| Vgs (Max) |
±20V |
|
| Technology |
GaNFET (Gallium Nitride) |
|
| Supplier Device Package |
TO-247-3 |
|
| Series |
SuperGaN™ |
|
| Rds On (Max) @ Id, Vgs |
18mOhm @ 60A, 10V |
|
| Power Dissipation (Max) |
266W (Tc) |
|
| Package / Case |
TO-247-3 |
|
| Package |
Tube |
|
| Product Attribute |
Attribute Value
| |
| Operating Temperature |
-55°C ~ 150°C (TJ) |
|
| Mounting Type |
Through Hole |
|
| Input Capacitance (Ciss) (Max) @ Vds |
5218 pF @ 400 V |
|
| Gate Charge (Qg) (Max) @ Vgs |
100 nC @ 10 V |
|
| FET Type |
N-Channel |
|
| FET Feature |
- |
|
| Drive Voltage (Max Rds On, Min Rds On) |
10V |
|
| Drain to Source Voltage (Vdss) |
650 V |
|
| Current - Continuous Drain (Id) @ 25°C |
93A (Tc) |
|
