Specifications
231-843/001-000 Tech Specifications
WAGO Corporation - 231-843/001-000 technical specifications, attributes, parameters and parts with similar specifications to WAGO Corporation - 231-843/001-000
| Product Attribute |
Attribute Value
| |
| Manufacturer |
WAGO |
|
| Wire Strip Length |
- |
|
| Wire Gauge or Range - mm² |
- |
|
| Wire Gauge or Range - AWG |
- |
|
| Voltage - UL |
600 V |
|
| Voltage - IEC |
1 kV |
|
| Type |
Header, Male Pins, Shrouded (4 Side) |
|
| Torque - Screw |
- |
|
| Termination Style |
Solder |
|
| Series |
MCSMIDI Classic |
|
| Screw Size |
- |
|
| Positions Per Level |
13 |
|
| Plug Wire Entry |
- |
|
| Pitch |
0.295" (7.50mm) |
|
| Package |
Box |
|
| Operating Temperature |
-60°C ~ 100°C |
|
| Product Attribute |
Attribute Value
| |
| Number of Positions |
13 |
|
| Number of Levels |
1 |
|
| Mounting Type |
Through Hole |
|
| Material Flammability Rating |
UL94 V-0 |
|
| Insulation Height |
0.331" (8.40mm) |
|
| Ingress Protection |
- |
|
| Housing Material |
Polyamide (PA66), Nylon 6/6 |
|
| Header Orientation |
90°, Right Angle |
|
| Features |
- |
|
| Current - UL |
10 A |
|
| Current - IEC |
12A |
|
| Contact Tail Length |
0.150" (3.81mm) |
|
| Contact Mating Finish |
Tin |
|
| Contact Material |
Electrolytic Copper |
|
| Color |
Gray |
|
