Specifications
721-103/008-000 Tech Specifications
WAGO Corporation - 721-103/008-000 technical specifications, attributes, parameters and parts with similar specifications to WAGO Corporation - 721-103/008-000
| Product Attribute |
Attribute Value
| |
| Manufacturer |
WAGO |
|
| Wire Strip Length |
8-9mm |
|
| Wire Gauge or Range - mm² |
0.08-2.5mm² |
|
| Wire Gauge or Range - AWG |
12-28 AWG |
|
| Voltage - UL |
600 V |
|
| Voltage - IEC |
630 V |
|
| Type |
Plug, Female Sockets |
|
| Torque - Screw |
- |
|
| Termination Style |
Screwless - Push-In Spring |
|
| Series |
MCSMIDI |
|
| Screw Size |
- |
|
| Positions Per Level |
3 |
|
| Plug Wire Entry |
180° |
|
| Pitch |
0.197" (5.00mm) |
|
| Package |
Box |
|
| Operating Temperature |
-60°C ~ 85°C |
|
| Product Attribute |
Attribute Value
| |
| Number of Positions |
3 |
|
| Number of Levels |
1 |
|
| Mounting Type |
Free Hanging (In-Line) |
|
| Material Flammability Rating |
UL94 V-0 |
|
| Insulation Height |
0.563" (14.30mm) |
|
| Ingress Protection |
- |
|
| Housing Material |
Polyamide (PA66), Nylon 6/6 |
|
| Header Orientation |
- |
|
| Features |
Board Lock, Retention Latches (Non-Wire Side) |
|
| Current - UL |
15 A |
|
| Current - IEC |
16A |
|
| Contact Tail Length |
- |
|
| Contact Mating Finish |
Tin |
|
| Contact Material |
Copper Alloy |
|
| Color |
Gray |
|
