ADS1220IRVAT Image
ADS1220IRVAT Image - 1ADS1220IRVAT Image - 2
Image may be representation.
See specifications for product details.
Share
 Favorite
EXPRESS OPTION
Payment method

ADS1220IRVAT - Texas Instruments

Manufacturer Part Number
ADS1220IRVAT
Manufacturer
Texas Instruments
Allelco Part Number
32D-ADS1220IRVAT
Warranty
1 Year Allelco Warranty - Find out more
Parts Description
IC ADC 24BIT SIGMA-DELTA 16VQFN
Package
16-VQFN (3.5x3.5)
Data sheet
1.ADS1220IRVAT.pdf ...
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 3617
  • Unit Price: $2.317
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $2.317 $2.32
10+ $2.021 $20.21
30+ $1.844 $55.32
250+ $1.666 $416.50
500+ $1.583 $791.50
1000+ $1.546 $1,546.00
The above prices does not include taxes and freight rates, which will be calculated on the order pages.
EXPRESS OPTION
Payment method
Our certification

Specifications

ADS1220IRVAT Tech Specifications
Texas Instruments - ADS1220IRVAT technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments - ADS1220IRVAT

Product Attribute Attribute Value
Manufacturer Texas Instruments
Voltage - Supply, Digital 2.3V ~ 5.5V
Voltage - Supply, Analog 2.3V ~ 5.5V, ±2.5
Supplier Device Package 16-VQFN (3.5x3.5)
Series -
Sampling Rate (Per Second) 2k
Reference Type External, Internal, Supply
Ratio - S/H:ADC -
Package / Case 16-VFQFN Exposed Pad
Package Tape & Reel (TR)
Operating Temperature -40°C ~ 125°C
Product Attribute Attribute Value
Number of Inputs 2, 4
Number of Bits 24
Number of A/D Converters 1
Mounting Type Surface Mount
Input Type Differential, Single Ended
Features PGA, Temperature Sensor
Data Interface SPI
Configuration MUX-PGA-ADC
Base Product Number ADS1220
Architecture Sigma-Delta

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

Parts Introduction

Manufacturer Part Number

ADS1220IRVAT

Manufacturer

Texas Instruments

Introduction

Precision 24-Bit ADC with Low Noise and Low Power Consumption

Product Features and Performance

High Precision 24-Bit Analog to Digital Converter

Multiple Channels with Flexible Input Types

Programmable Gain Amplifier for Sensor Signal Amplification

Integrated Temperature Sensor for Thermal Monitoring

Sampling Rate up to 2k Samples Per Second

Sigma-Delta Architecture Ensuring High Noise Immunity

Digital Supply Voltage Compatibility from 2.3V to 5.5V

Small Form Factor with VFQFN Package

Product Advantages

Low Power Operation Suitable for Battery-Powered Devices

Various Reference Voltage Options Offering Design Flexibility

Supports Multiple Input Configurations to Interface with Various Sensors

SPI Interface for Easy Integration into Digital Systems

Key Technical Parameters

Number of Bits: 24

Sampling Rate: 2k SPS

Number of Inputs: 2 to 4 (Differential, Single Ended)

Architecture: Sigma-Delta

Voltage Supply Range: 2.3V ~ 5.5V (Analog & Digital)

Temperature Range: -40°C ~ 125°C

Quality and Safety Features

Extended Operating Temperature Range for Harsh Environments

Robust VFQFN Package for Enhanced Thermal and Mechanical Performance

Compatibility

Configurable Inputs and SPI Interface for Broad Microcontroller Compatibility

Mounting Type: Surface Mount for Standard PCB Assembly Processes

Application Areas

Industrial Measurement and Automation

Precision Sensor Data Acquisition

Medical Instruments

Battery-Powered Equipment

Portable Instrumentation

Product Lifecycle

Active Status, Not Nearing Discontinuation

Future Replacement or Upgrade Options Likely due to Active Status

Several Key Reasons to Choose This Product

Exceptional Resolution and Accuracy for Critical Measurement Applications

Flexibility in Handling Differential and Single-Ended Inputs

Embedded Programmable Gain Amplifier and Temperature Sensor Minimize External Component Count

Low Power Consumption Suitable for Energy-Sensitive Applications

Sturdy Package and Extended Temperature Range Make It Ideal for Industrial Use

Parts with Similar Specifications
