Manufacturer Part Number
TPS561208DDCR
Manufacturer
Texas Instruments
Introduction
The TPS561208DDCR is a step-down (buck) regulator from Texas Instruments with high efficiency and power-saving capabilities.
Product Features and Performance
Buck topology for efficient step-down voltage conversion
Adjustable output voltage from 0.76V to 7V
1A maximum output current
Wide input voltage range from 4.5V to 17V
High switching frequency of 580kHz for smaller external components
Integrated synchronous rectifier to improve efficiency
Capable of operating from -40°C to 125°C
SWIFT™ series with advanced power management features
Product Advantages
High-efficiency power conversion, reducing heat and improving system performance
Small SOT-23-6 package saves PCB space
Adjustable voltage output for a range of applications
Compatible with a wide range of input voltages
Thermal shutdown and overcurrent protection enhance safety and reliability
Key Technical Parameters
Voltage Input (Min) 4.5V
Voltage Input (Max) 17V
Voltage Output (Min/Fixed) 0.76V
Voltage Output (Max) 7V
Current Output 1A
Frequency Switching 580kHz
Quality and Safety Features
Overcurrent protection
Thermal shutdown
Operating temperature range from -40°C to 125°C ensures reliable performance in a variety of environments
Compatibility
Surface mount compatible with standard reflow soldering processes
Compatible with various input voltages suitable for a broad range of electronics
Application Areas
Consumer electronics
Power supplies
Portable devices
Networking equipment
Industrial controls
Product Lifecycle
Active status, indicating current production with support and availability
Not reported as nearing discontinuation, replacements or upgrades should be available if needed
Several Key Reasons to Choose This Product
Versatile and efficient for power management applications
Space-saving design for compact electronics
High degree of integration reduces the need for external components, lowering system cost
Reliable performance with quality and safety protections built-in
Made by Texas Instruments, a leading manufacturer known for durability and performance
TPS56100PWPTexas InstrumentsIC REG CTRLR 1OUT 28HTSSOP
TPS561201EVM-896Texas InstrumentsEVAIL MOD
TPS56100EVM-133Texas InstrumentsHIGH-PERFORMANCE SYNCHRONOUS BUC
TPS561208EVM-896Texas InstrumentsEVAIL MOD
TPS56121EVM-601Texas InstrumentsEVAL MODULE FOR TPS56121-601
