STOD13AMTPUR - STMicroelectronics

Manufacturer Part Number
STOD13AMTPUR
Manufacturer
STMicroelectronics
Allelco Part Number
32D-STOD13AMTPUR
Warranty
1 Year Allelco Warranty - Find out more
Stock Status:
28,305 pcs available, New & Original
Parts Description
IC REG AMOLED DISPLAY 2OUT 12DFN
Package
12-DFN (3x3)
Data sheet
STOD13AMTPUR.pdf

Datasheets

STOD13AM.pdf

PCN Obsolescence/ EOL

STODx Obs 22/Apr/2015.pdf
RoHs Status
ROHS3 Compliant
Compare
Our certification
In stock: 28305
  • Unit Price: $1.153
  • Subtotal: $0.00

Want a better price?
Add to Cart and Submit RFQ now, we'll contact you immediately.

Quantity Unit Price Ext. Price
1+ $1.153 $1.15
200+ $0.46 $92.00
500+ $0.445 $222.50
1000+ $0.438 $438.00
The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Specifications

STOD13AMTPUR Tech Specifications
STMicroelectronics - STOD13AMTPUR technical specifications, attributes, parameters and parts with similar specifications to STMicroelectronics - STOD13AMTPUR

Product Attribute Attribute Value
Manufacturer STMicroelectronics
Voltage - Output 4.6V, -2.4V ~ -5.4V
Voltage - Input 2.5V ~ 4.5V
Supplier Device Package 12-DFN (3x3)
Series -
Package / Case 12-UFDFN Exposed Pad
Product Attribute Attribute Value
Package Tape & Reel (TR)
Operating Temperature -40°C ~ 85°C
Number of Outputs 2
Mounting Type Surface Mount
Base Product Number STOD13
Applications Converter, AMOLED Display

Environmental & Export Classifications

ATTRIBUTE DESCRIPTION
RoHs Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001

Parts Introduction

STOD13AMTPUR Image
STOD13AMTPUR (1)

Manufacturer Part Number

STOD13AMTPUR

Manufacturer

stmicroelectronics

Introduction

The STOD13AMTPUR is designed for power management, specifically as a PMIC for special purpose regulators. It is tailored for use in AMOLED display converters.

Product Features and Performance

Integrated dual output display supply

Provides positive and negative voltage outputs

Input voltage range from 2.5V to 4.5V

Two output voltages: 4.6V and adjustable negative voltage ranging from -2.4V to -5.4V

Operating temperature ranges from -40°C to 85°C

Surface mount technology in a 12-UFDFN Exposed Pad package

Product Advantages

Compact 12-DFN package suitable for space-constrained applications

Integrated functionality reduces external component count

Wide input voltage range accommodates various power supplies

Ability to drive AMOLED displays directly

Key Technical Parameters

Voltage Input: 2.5V ~ 4.5V

Number of Outputs: 2

Voltage Output: 4.6V, -2.4V ~ -5.4V

Operating Temperature: -40°C ~ 85°C

Mounting Type: Surface Mount

Package / Case: 12-UFDFN Exposed Pad

Supplier Device Package: 12-DFN (3x3)

Quality and Safety Features

Built with stmicroelectronics' stringent quality control processes

Designed to meet high safety and performance standards

Compatibility

Specifically designed for power supply solutions in AMOLED display applications

Application Areas

AMOLED display modules

Portable electronic devices with display requirements

Any system requiring a compact power management solution for displays

Product Lifecycle

Obsolete

Replacement or upgrade models may be available through stmicroelectronics

Several Key Reasons to Choose This Product

Optimally designed for AMOLED displays, ensuring excellent display performance

Compact and efficient design reduces overall system size and power consumption

Supports a broad range of input voltages, enhancing compatibility with existing power supplies

The robust operating temperature range makes it suitable for a wide variety of environments and applications

Obsolete status implies potential for cost savings on bulk purchases for sustaining existing designs
