EPF10K70RC240-4N - Intel

Name: Intel EPF10K70RC240-4N
Brand: Intel
SKU: EPF10K70RC240-4N
Availability: InStock
Rating: 5 (10 reviews)

Manufacturer Part Number: EPF10K70RC240-4N

Manufacturer: Intel

Allelco Part Number: 32D-EPF10K70RC240-4N

Warranty: 1 Year Allelco Warranty - Find out more

Stock Status:: 4,270 pcs available, New & Original

Parts Description: IC FPGA 189 I/O 240RQFP

Package: 240-RQFP (32x32)

Data sheet: EPF10K70RC240-4.pdf

Datasheets
FLEX 10K.pdf

PCN Packaging
All Dev Pkg Chg 1/Aug/2018.pdf Mult Dev Dessicant Chg 19/Jul/2019.pdf

PCN Obsolescence/ EOL
EOL 01/Dec/2016.pdf EOL 21/Nov/2016.pdf

PCN Design/Specification
Laser Mark 17/Feb/2016.pdf Mult Series Software Chgs 26/Mar/2020.pdf

PCN Other
Software Disc 06/Nov/2020.pdf

RoHs Status

~~Compare~~

Our certification

In stock: 4270

Specifications

EPF10K70RC240-4N Tech Specifications
Intel - EPF10K70RC240-4N technical specifications, attributes, parameters and parts with similar specifications to Intel - EPF10K70RC240-4N

Product Attribute	Attribute Value
Manufacturer	Intel
Voltage - Supply	4.75V ~ 5.25V
Total RAM Bits	18432
Supplier Device Package	240-RQFP (32x32)
Series	FLEX-10K®
Package / Case	240-BFQFP Exposed Pad
Package	Tray

Product Attribute	Attribute Value
Operating Temperature	0°C ~ 70°C (TA)
Number of Logic Elements/Cells	3744
Number of LABs/CLBs	468
Number of I/O	189
Number of Gates	118000
Mounting Type	Surface Mount
Base Product Number	EPF10K70

Environmental & Export Classifications

ATTRIBUTE	DESCRIPTION
Moisture Sensitivity Level (MSL)	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	3A001A2A
HTSUS	8542.39.0001

Parts Introduction

EPF10K70RC240-4N (1)

Manufacturer Part Number

EPF10K70RC240-4N

Manufacturer

Intel

Introduction

The EPF10K70RC240-4N is part of the FLEX-10K® series of Embedded FPGAs (Field Programmable Gate Array) designed by Intel for high-performance programmable logic solutions.

Product Features and Performance

Embedded FPGA with 3744 logic elements/cells and 468 LABs/CLBs

Offers a total of 18432 RAM bits for data storage

Features a high number of I/O with 189 pins

Provides a substantial gate count of 118000 for complex designs

Product Advantages

High-density integration suited for advanced programmable logic

Robust temperature range (0°C ~ 70°C) ensuring operational stability

Surface mount technology for solid board level attachment

Key Technical Parameters

Voltage Supply: 4.75V ~ 5.25V

Operating Temperature: 0°C ~ 70°C

Package: 240-BFQFP Exposed Pad

118000 gates, 3744 logic elements/cells, 468 LABs/CLBs

Quality and Safety Features

Manufactured by Intel, ensuring high standards of quality and reliability

Robust packaging (240-BFQFP Exposed Pad) designed for enhanced thermal and mechanical performance

Compatibility

Compatible with various design software and hardware tools for FPGA programming and simulation

Application Areas

Telecommunications, automotive, industrial control, and consumer electronics industries

Product Lifecycle

Classified as Obsolete

Potential limited availability, recommend verifying alternatives or upgrade paths due to discontinuation

Several Key Reasons to Choose This Product

High logic and RAM capacity ideal for complex programmable solutions

Supported by Intel's reputation for reliability in semiconductor manufacturing

Broad operational temperature suitable for varied environmental conditions

Strong community and resource support for development and troubleshooting
